33
CDX-CA600/CA600X
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
DISPLAY BOARD
**************
* 3-227-293-01 SHEET (LCD)
* 3-229-751-01 SHEET (LCD.UP)
3-236-920-01 SHEET (LCD), DIFFUSION
3-236-921-01 PLATE (LCD), GROUND
< CAPACITOR >
C501 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C502 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CNP551 1-779-131-11 PIN, CONNECTOR 2P
CNP552 1-794-312-21 PIN, CONNECTOR 12P
< DIODE >
D501 8-719-068-68 DIODE SDZ6V2WA
D502 8-719-069-56 DIODE UDZS-TE-17-6.2B
D503 8-719-069-54 DIODE UDZS-TE-17-5.1B
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-069-54 DIODE UDZS-TE-17-5.1B
D506 8-719-988-61 DIODE 1SS355TE-17 (CA600)
D531 8-719-077-34 LED SML-310YTT86 (OFF) (CA600)
D532 8-719-077-34 LED SML-310YTT86 (TA) (CA600)
D533 8-719-077-34 LED SML-310YTT86 (SENS/BTM) (CA600)
D534 8-719-053-08 LED SML-310DTT86 (SEEK4) (CA600)
D535 8-719-053-08 LED SML-310DTT86 (SEEK5) (CA600)
D536 8-719-077-34 LED SML-310YTT86 (Z) (CA600)
D537 8-719-053-08 LED SML-310DTT86 (SEEK3) (CA600)
D538 8-719-053-08 LED SML-310DTT86 (D-BASS) (CA600)
D539 8-719-053-08 LED SML-310DTT86 (SEEK1) (CA600)
D540 8-719-053-08 LED SML-310DTT86 (SEEK2) (CA600)
D541 8-719-053-08 LED SML-310DTT86 (LIST/PTY) (CA600)
D542 8-719-053-08 LED SML-310DTT86 (MBP) (CA600)
D543 8-719-077-34 LED SML-310YTT86 (6) (CA600)
D544 8-719-077-34 LED SML-310YTT86 (5) (CA600)
D545 8-719-077-34 LED SML-310YTT86 (4/SHUF) (CA600)
D546 8-719-077-34 LED SML-310YTT86 (3/REP) (CA600)
D547 8-719-077-34 LED SML-310YTT86 (2/DISC +) (CA600)
D548 8-719-077-34 LED SML-310YTT86 (1/DISC –) (CA600)
D549 8-719-077-34 LED SML-310YTT86 (ATT) (CA600)
D550 8-719-077-34 LED SML-310YTT86 (AF) (CA600)
D551 8-719-053-08 LED SML-310DTT86 (DSPL) (CA600)
D552 8-719-053-08 LED SML-310DTT86 (VOL2) (CA600)
D553 8-719-053-08 LED SML-310DTT86 (VOL1) (CA600)
D554 8-719-077-34 LED SML-310YTT86 (MODE) (CA600)
D555 8-719-053-08 LED SML-310DTT86 (SOURCE) (CA600)
D556 8-719-053-08 LED SML-310DTT86 (VOL5) (CA600)
D557 8-719-053-08 LED SML-310DTT86 (SEL) (CA600)
D558 8-719-053-08 LED SML-310DTT86 (VOL4) (CA600)
D559 8-719-053-08 LED SML-310DTT86 (VOL3) (CA600)
D561 8-719-038-05 LED CL-190FG-CD-T (OFF) (CA600)
D561 8-719-053-09 LED SML-310VTT86 (OFF) (CA600X)
D562 8-719-038-05 LED CL-190FG-CD-T (TA) (CA600)
D562 8-719-053-09 LED SML-310VTT86 (TA) (CA600X)
D563 8-719-038-05 LED CL-190FG-CD-T (SENS/BTM) (CA600)
D563 8-719-053-09 LED SML-310VTT86 (SENS/BTM) (CA600X)
D564 8-719-053-09 LED SML-310VTT86 (SEEK4) (CA600X)
D564 8-719-078-21 LED SML-310PTT86 (SEEK4) (CA600)
D565 8-719-053-09 LED SML-310VTT86 (SEEK5) (CA600X)
D565 8-719-078-21 LED SML-310PTT86 (SEEK5) (CA600)
D566 8-719-038-05 LED CL-190FG-CD-T (Z) (CA600)
D566 8-719-053-09 LED SML-310VTT86 (Z) (CA600X)
D567 8-719-053-09 LED SML-310VTT86 (SEEK3) (CA600X)
D567 8-719-078-21 LED SML-310PTT86 (SEEK3) (CA600)
D568 8-719-053-09 LED SML-310VTT86 (D-BASS) (CA600X)
D568 8-719-078-21 LED SML-310PTT86 (D-BASS) (CA600)
D569 8-719-053-09 LED SML-310VTT86 (SEEK1) (CA600X)
D569 8-719-078-21 LED SML-310PTT86 (SEEK1) (CA600)
D570 8-719-053-09 LED SML-310VTT86 (SEEK2) (CA600X)
D570 8-719-078-21 LED SML-310PTT86 (SEEK2) (CA600)
D571 8-719-053-09 LED SML-310VTT86 (LIST/PTY) (CA600X)
D571 8-719-078-21 LED SML-310PTT86 (LIST/PTY) (CA600)
D572 8-719-053-09 LED SML-310VTT86 (MBP) (CA600X)
D572 8-719-078-21 LED SML-310PTT86 (MBP) (CA600)
D573 8-719-038-05 LED CL-190FG-CD-T (6) (CA600)
D573 8-719-053-09 LED SML-310VTT86 (6) (CA600X)
D574 8-719-038-05 LED CL-190FG-CD-T (5) (CA600)
D574 8-719-053-09 LED SML-310VTT86 (5) (CA600X)
D575 8-719-038-05 LED CL-190FG-CD-T (4/SHUF) (CA600)
D575 8-719-053-09 LED SML-310VTT86 (4/SHUF) (CA600X)
D576 8-719-038-05 LED CL-190FG-CD-T (3/REP) (CA600)
D576 8-719-053-09 LED SML-310VTT86 (3/REP) (CA600X)
D577 8-719-038-05 LED CL-190FG-CD-T (2/DISC +) (CA600)
D577 8-719-053-09 LED SML-310VTT86 (2/DISC +) (CA600X)
D578 8-719-038-05 LED CL-190FG-CD-T (1/DISC –) (CA600)
D578 8-719-053-09 LED SML-310VTT86 (1/DISC –) (CA600X)
D579 8-719-038-05 LED CL-190FG-CD-T (ATT) (CA600)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
