34
CDX-CA600/CA600X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
D579 8-719-053-09 LED SML-310VTT86 (ATT) (CA600X)
D580 8-719-038-05 LED CL-190FG-CD-T (AF) (CA600)
D580 8-719-053-09 LED SML-310VTT86 (AF) (CA600X)
D581 8-719-053-09 LED SML-310VTT86 (DSPL) (CA600X)
D581 8-719-078-21 LED SML-310PTT86 (DSPL) (CA600)
D582 8-719-053-09 LED SML-310VTT86 (VOL2) (CA600X)
D582 8-719-078-21 LED SML-310PTT86 (VOL2) (CA600)
D583 8-719-053-09 LED SML-310VTT86 (VOL1) (CA600X)
D583 8-719-078-21 LED SML-310PTT86 (VOL1) (CA600)
D584 8-719-038-05 LED CL-190FG-CD-T (MODE) (CA600)
D584 8-719-053-09 LED SML-310VTT86 (MODE) (CA600X)
D585 8-719-053-09 LED SML-310VTT86 (SOURCE) (CA600X)
D585 8-719-078-21 LED SML-310PTT86 (SOURCE) (CA600)
D586 8-719-053-09 LED SML-310VTT86 (VOL5) (CA600X)
D586 8-719-078-21 LED SML-310PTT86 (VOL5) (CA600)
D587 8-719-053-09 LED SML-310VTT86 (SEL) (CA600X)
D587 8-719-078-21 LED SML-310PTT86 (SEL) (CA600)
D588 8-719-053-09 LED SML-310VTT86 (VOL4) (CA600X)
D588 8-719-078-21 LED SML-310PTT86 (VOL4) (CA600)
D589 8-719-053-09 LED SML-310VTT86 (VOL3) (CA600X)
D589 8-719-078-21 LED SML-310PTT86 (VOL3) (CA600)
< IC >
IC501 8-759-366-34 IC LC75824E
IC552 8-749-017-35 IC KSM-401N
< JUMPER RESISTOR >
JR501 1-216-864-11 METAL CHIP 0 5% 1/16W
JR502 1-216-864-11 METAL CHIP 0 5% 1/16W
JR503 1-216-864-11 METAL CHIP 0 5% 1/16W
JR504 1-216-864-11 METAL CHIP 0 5% 1/16W
JR505 1-216-864-11 METAL CHIP 0 5% 1/16W
JR506 1-216-295-11 SHORT 0 (CA600)
JR507 1-216-864-11 METAL CHIP 0 5% 1/16W
(CA600)
JR508 1-216-864-11 METAL CHIP 0 5% 1/16W
JR509 1-216-864-11 METAL CHIP 0 5% 1/16W
JR510 1-216-864-11 METAL CHIP 0 5% 1/16W
JR511 1-216-864-11 METAL CHIP 0 5% 1/16W
(CA600)
JR512 1-216-295-11 SHORT 0
JR513 1-216-864-11 METAL CHIP 0 5% 1/16W
JR514 1-216-295-11 SHORT 0
JR515 1-216-864-11 METAL CHIP 0 5% 1/16W
JR516 1-216-295-11 SHORT 0
JR517 1-216-864-11 METAL CHIP 0 5% 1/16W
(CA600)
JR518 1-216-295-11 SHORT 0 (CA600)
JR519 1-216-864-11 METAL CHIP 0 5% 1/16W
(CA600)
JR520 1-216-864-11 METAL CHIP 0 5% 1/16W
(CA600X)
< LIQUID CRYSTAL DISPLAY >
LCD501 1-804-623-11 DISPLAY PANEL, LIQUID CRYSTAL (CA600)
LCD501 1-804-623-21 DISPLAY PANEL, LIQUID CRYSTAL (CA600X)
< DIODE >
LED549 6-500-083-01 LED NSPW315BSRS (LCD BACK LIGHT)
LED550 6-500-083-01 LED NSPW315BSRS (LCD BACK LIGHT)
< TRANSISTOR >
Q501 8-729-904-66 TRANSISTOR DTD113EK-T-146 (CA600)
Q502 8-729-904-66 TRANSISTOR DTD113EK-T-146 (CA600)
Q503 8-729-144-85 FET 2SK1133 (CA600)
< RESISTOR >
R501 1-219-286-11 RES-CHIP 680 2% 1/16W
R502 1-219-286-11 RES-CHIP 680 2% 1/16W
R503 1-219-286-11 RES-CHIP 680 2% 1/16W
R504 1-218-847-11 RES-CHIP 1K 2% 1/16W
R505 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R506 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R507 1-218-855-11 RES-CHIP 2.2K 2% 1/16W
R508 1-218-859-11 RES-CHIP 3.3K 2% 1/16W
R509 1-218-863-11 RES-CHIP 4.7K 2% 1/16W
R510 1-218-867-11 RES-CHIP 6.8K 2% 1/16W
R511 1-219-286-11 RES-CHIP 680 2% 1/16W
R512 1-219-286-11 RES-CHIP 680 2% 1/16W
R513 1-219-286-11 RES-CHIP 680 2% 1/16W
R514 1-218-847-11 RES-CHIP 1K 2% 1/16W
R515 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R516 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R517 1-218-855-11 RES-CHIP 2.2K 2% 1/16W
R518 1-218-859-11 RES-CHIP 3.3K 2% 1/16W
R519 1-218-863-11 RES-CHIP 4.7K 2% 1/16W
R520 1-218-867-11 RES-CHIP 6.8K 2% 1/16W
R521 1-218-867-11 RES-CHIP 6.8K 2% 1/16W
R522 1-216-821-11 METAL CHIP 1K 5% 1/16W
R523 1-216-821-11 METAL CHIP 1K 5% 1/16W
R524 1-216-821-11 METAL CHIP 1K 5% 1/16W
R525 1-216-821-11 METAL CHIP 1K 5% 1/16W
R526 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(CA600)
R550 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
(CA600)
R551 1-216-807-11 METAL CHIP 68 5% 1/16W
R552 1-216-819-11 METAL CHIP 680 5% 1/16W
R553 1-216-813-11 METAL CHIP 220 5% 1/16W
R554 1-216-857-11 METAL CHIP 1M 5% 1/16W
R555 1-216-850-11 METAL CHIP 270K 5% 1/16W
R556 1-216-821-11 METAL CHIP 1K 5% 1/16W
R557 1-216-821-11 METAL CHIP 1K 5% 1/16W
R558 1-216-821-11 METAL CHIP 1K 5% 1/16W
R559 1-220-373-11 RES-CHIP 620 5% 1/16W
