CDX-CA600/CA600X
Pin No. Pin Name I/O Pin Description
51 TSTB O CD text parameter strob signal output to servo IC (IC1)
52 RFOK I RF OK signal input from servo IC (IC1)
53 CD RST O Reset signal output to servo IC (IC1)
54 A0 O
Command/parameter identification signal output to servo IC (IC1)
“L”: Command, “H”: Parameter
55 STB O Data strob signal output to servo IC (IC1)
56 X EN O Crystal oscillation control signal output to servo IC (IC1)
57 LIMIT I CD Mechanism in-limit switch signal input from limit switch (SW4)
58 PH1 I CD Mechanism PH1 detection signal input Not used in this set.
59 D SW I CD Mechanism down switch signal input from down switch (SW1)
60 INSW/PH2 I CD Mechanism disc-in switch detection signal input from disc-in switch (SW3)
61 PH3 I CD Mechanism PH3 detection signal input Not used in this set.
62 CD LM LO O CD Mechanism loading motor control signal output to loading motor drive (IC2)
63 CD LM EJ O CD Mechanism eject motor control signal output to loading motor drive (IC2)
64, 65 NC O Not used. (Open)
66 AMPATT O Power amp ATT control signal output to power amp (IC401)
67 AMPON O Power amp standby control signal output to power amp (IC401)
68 CDMD ON O CD mechanism deck power supply control signal output
69 ATT O System ATT control signal output
70 VOLATT O Electrical volume ATT control signal output to electrical volume (IC402)
71 – 75 NC O Not used. (Open)
76 NC I Not used. (Open)
77 COL SEL I Color select switch signal input “H”: Green, “L”: Amber
78 NC O Not used. (Open)
79 XCD ON O CD on signal output “H”: Play, “L”: Loading or standby
80 – 85 NC O Not used. (Open)
86 EE SIO I/O EEPROM serial data signal input/output
87 EE CKO O EEPROM serial clock signal output
88 NC O Not used. (Open)
89 FLASH W I Flash microcomputer write detection signal input “L”: Write mode
90 NS MASK O Noise mask signal output
91 AD ON O Key power supply control signal output
92 DOORIND O Sub panel power supply control signal output Not used in this set. (Open)
93 ILLON O Illumination power supply control signal output
94 NOSE SW I Front panel with/without detection signal input “L”: Panel with, “H”: Panel without
95 DAVSS — Ground pin
96 RE IN1 I Rotary encoder signal input Not used in this set. (Open)
97 RE IN0 I Rotary encoder signal input Not used in this set. (Open)
98 RC IN1 I
Rotary commander shift key signal input from remote in jack (CNP801)
“L”: Shift key on
99 NC O Not used. (Open)
100 DAVDD — Power supply pin (+5 V)
