3-16. PRINTED WIRING BOARD — KEY SECTION —
(Page 38)
Ref. No. Location
(D900) A-12
(D901) A-11
(D902) B-12
(D910) B-3
D920 B-13
(D972) A-9
(D974) A-9
(IC901) B-8
(IC902) B-1
• Semiconductor Location
Ref. No. Location
(IC903) B-3
(LED900) B-1
LED910 B-12
LED911 B-2
LED912 B-12
LED913 B-2
(Q903) C-11
( ) : SIDE B
