CDX-CA850/CA850X/CA860X
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DISC IN
* 1-659-836-11 DISC IN BOARD
*************
< SWITCH >
SW1 1-572-288-21 SWITCH, PUSH (DISC IN)
SW2 1-572-288-21 SWITCH, PUSH (SELF)
*************************************************************
KEY BOARD
**********
1-694-780-11 CONDUCTIVE BOARD, CONNECTION
* 3-227-278-01 PLATE (LCD), LIGHT GUIDE
* 3-227-279-01 PLATE (LCD), GROUND
* 3-227-280-01 CASE (IR-T), SHIELD
* 3-227-283-01 SHEET (ILLUMINATOR)
* 3-227-284-01 SHEET (REFLECTOR)
* 3-230-625-01 SHEET
< CAPACITOR >
C900 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C901 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C902 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C903 1-135-852-21 ELECT CHIP 22uF 20% 6.3V
C904 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C905 1-135-852-21 ELECT CHIP 22uF 20% 6.3V
C906 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C907 1-164-388-11 CERAMIC CHIP 270PF 5% 50V
C908 1-115-156-11 CERAMIC CHIP 1uF 10V
C910 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C912 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C982 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C983 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C986 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C990 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C991 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C992 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C993 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-794-065-22 PLUG, CONNECTOR 14P
< DIODE >
D900 8-719-078-81 DIODE DF5A6.8FU(TE85R)
D901 8-719-018-01 DIODE MA8220-TX
D902 8-719-017-58 DIODE MA8068-TX
D910 8-719-073-01 DIODE MA111-(K8).S0
D920 8-719-420-90 DIODE MA8051-M-TX
D972 8-719-977-03 DIODE MA8056-M-TX
D974 8-719-422-94 DIODE MA8091-L-TX
< FERRITE BEAD >
FB901 1-414-235-22 INDUCTOR, FERRITE BEAD
FB902 1-414-235-22 INDUCTOR, FERRITE BEAD
< IC >
IC901 8-759-653-26 IC LC75878W
IC902 8-759-830-18 IC RRX9000-0601#1
IC903 8-759-830-17 IC RRX9000-0401R#01
< LIQUID CRYSTAL DISPLAY >
LCD901 1-804-308-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED900 8-719-083-14 LED RRX9000-0501 (IR RECEIVE)
LED910 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED911 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED912 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED913 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
< SWITCH >
LSW921 1-762-619-21 SWITCH, KEYBOARD (WITH LED) (ON/OFF)
< TRANSISTOR >
Q903 8-729-904-75 TRANSISTOR DTD114EK-T-146
< RESISTOR >
R900 1-216-819-11 METAL CHIP 680 5% 1/16W
R901 1-216-037-00 METAL CHIP 330 5% 1/10W
R902 1-216-846-11 METAL CHIP 120K 5% 1/16W
R903 1-216-851-11 METAL CHIP 330K 5% 1/16W
R904 1-216-037-00 METAL CHIP 330 5% 1/10W
R905 1-216-295-11 SHORT 0
R910 1-216-821-11 METAL CHIP 1K 5% 1/16W
R911 1-216-857-11 METAL CHIP 1M 5% 1/16W
R912 1-216-817-11 METAL CHIP 470 5% 1/16W
R913 1-216-845-11 METAL CHIP 100K 5% 1/16W
