Sony CDX-CA850X - Page 52

52
CDX-CA850/CA850X/CA860X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
LIMIT LOAD
MAIN
R914 1-216-845-11 METAL CHIP 100K 5% 1/16W
R915 1-216-845-11 METAL CHIP 100K 5% 1/16W
R916 1-216-845-11 METAL CHIP 100K 5% 1/16W
R917 1-216-845-11 METAL CHIP 100K 5% 1/16W
R918 1-216-845-11 METAL CHIP 100K 5% 1/16W
R919 1-216-797-11 METAL CHIP 10 5% 1/16W
R921 1-216-029-00 METAL CHIP 150 5% 1/10W
R922 1-216-029-00 METAL CHIP 150 5% 1/10W
R923 1-216-029-00 METAL CHIP 150 5% 1/10W
R924 1-216-029-00 METAL CHIP 150 5% 1/10W
R971 1-216-029-00 METAL CHIP 150 5% 1/10W
R972 1-216-027-00 METAL CHIP 120 5% 1/10W
R973 1-216-029-00 METAL CHIP 150 5% 1/10W
R974 1-216-027-00 METAL CHIP 120 5% 1/10W
R979 1-216-041-00 METAL CHIP 470 5% 1/10W
R980 1-216-029-00 METAL CHIP 150 5% 1/10W
R981 1-216-029-00 METAL CHIP 150 5% 1/10W
R982 1-216-029-00 METAL CHIP 150 5% 1/10W
R983 1-216-857-11 METAL CHIP 1M 5% 1/16W
R984 1-216-821-11 METAL CHIP 1K 5% 1/16W
R985 1-216-821-11 METAL CHIP 1K 5% 1/16W
R986 1-216-821-11 METAL CHIP 1K 5% 1/16W
R987 1-216-841-11 METAL CHIP 47K 5% 1/16W
R988 1-216-029-00 METAL CHIP 150 5% 1/10W
R990 1-216-041-00 METAL CHIP 470 5% 1/10W
R991 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R992 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R993 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R994 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VIBRATOR >
X910 1-781-646-21 VIBRATOR, CERAMIC (4MHz)
*************************************************************
* 1-659-835-11 LIMIT BOARD
***********
< SWITCH >
SW3 1-572-688-11 SWITCH, PUSH (1 KEY) (LIMIT)
*************************************************************
* 1-659-837-11 LOAD BOARD
*********
< SWITCH >
SW4 1-572-288-21 SWITCH, PUSH (DOWN)
*************************************************************
KEY
* A-3283-144-A MAIN BOARD, COMPLETE (CA850)
* A-3283-145-A MAIN BOARD, COMPLETE (CA860X)
* A-3283-146-A MAIN BOARD, COMPLETE (CA850X)
*********************
1-790-355-53 CORD (WITH CONNECTOR) (RCA)
(SUB OUT (MONO))
* 3-040-998-01 BRACKET (IC)
* 3-223-780-01 HEAT SINK (CA850)
* 3-223-780-21 HEAT SINK (CA850X/CA860X)
* 3-223-783-21 CHASSIS (BACK)
* 3-223-785-01 HEAT SINK (REG/D)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
7-685-790-01 SCREW +PTT 2.6X4 (S)
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-794-09 SCREW +PTT 2.6X10 (S)
7-685-797-09 SCREW +PTT 2.6X16 (S)
< CAPACITOR >
C102 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C103 1-124-259-11 ELECT 4.7uF 20% 16V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C107 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C108 1-126-936-11 ELECT 3300uF 20% 16V
C201 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C202 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C203 1-124-589-11 ELECT 47uF 20% 16V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C205 1-126-154-11 ELECT 47uF 20% 6.3V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CA850)
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(CA850)
C208 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
(CA850)
C209 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
(CA850)
C210 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(CA850)
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(CA850)
C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(CA850)
C213 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(CA850)
C214 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
(CA850)
C215 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(CA850)
C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(CA850)
C217 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CA850)
C218 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CA850)
