55
CDX-CA850/CA850X/CA860X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
CN401 1-764-617-12 PIN, CONNECTOR (PC BOARD) 30P
CN601 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
CN701 1-784-456-11 CONNECTOR, FFC/FPC 14P
< JACK >
CN201 1-815-185-11 JACK (ANTENNA)
CN302 1-774-700-11 JACK, PIN 6P (BUS AUDIO IN,AUDIO OUT)
< DIODE >
D101 8-719-049-38 DIODE 1N5404TU
D102 8-719-017-58 DIODE MA8068
D105 8-719-073-01 DIODE MA111-(K8).S0
D106 8-719-053-18 DIODE 1SR154-400TE-25
D107 8-719-053-18 DIODE 1SR154-400TE-25
D110 8-719-975-40 DIODE RB411D-T146 (CA860X)
D202 8-719-073-01 DIODE MA111-(K8).S0
D203 8-719-422-41 DIODE MA8051-L-TX
D204 8-719-800-76 DIODE 1SS226 (CA850)
D301 8-719-200-82 DIODE 11ES2
D302 8-719-200-82 DIODE 11ES2
D303 8-719-200-82 DIODE 11ES2
D304 8-719-053-18 DIODE 1SR154-400TE-25
D305 8-719-200-82 DIODE 11ES2
D306 8-719-200-82 DIODE 11ES2
D307 8-719-200-82 DIODE 11ES2
D308 8-719-200-82 DIODE 11ES2
D310 8-719-801-78 DIODE 1SS184
D311 8-719-073-01 DIODE MA111-(K8).S0
D401 8-719-017-67 DIODE MA8068-H
D402 8-719-422-64 DIODE MA8062-M
D501 8-719-801-78 DIODE 1SS184
D503 8-719-977-03 DIODE DTZ5.6B
D504 8-719-073-01 DIODE MA111-(K8).S0
D505 8-719-422-41 DIODE MA8051-L-TX (CA850)
D601 8-719-073-01 DIODE MA111-(K8).S0
D603 8-719-017-94 DIODE MA8180
D604 8-719-420-51 DIODE MA729
D605 8-719-018-01 DIODE MA8220-TX
D606 8-719-018-01 DIODE MA8220-TX
D607 8-719-801-78 DIODE 1SS184
D608 8-719-073-01 DIODE MA111-(K8).S0
D609 8-719-422-64 DIODE MA8062-M
D610 8-719-073-01 DIODE MA111-(K8).S0
D653 8-719-820-05 DIODE 1SS181
D703 8-719-018-01 DIODE MA8220-TX
D707 8-719-017-58 DIODE MA8068
D708 8-719-018-01 DIODE MA8220-TX
D715 8-719-801-78 DIODE 1SS184
D801 8-719-420-14 DIODE MA8082-M
D802 8-719-420-92 DIODE MA8051-M-TX
< FERRITE BEAD >
FB201 1-414-235-22 INDUCTOR, FERRITE BEAD (CA850)
FB301 1-414-235-22 INDUCTOR, FERRITE BEAD
FB401 1-414-235-22 INDUCTOR, FERRITE BEAD
FB402 1-414-235-22 INDUCTOR, FERRITE BEAD
FB403 1-414-234-22 INDUCTOR, FERRITE BEAD (CA850X/CA860X)
FB403 1-414-235-22 INDUCTOR, FERRITE BEAD (CA850)
FB501 1-414-235-22 INDUCTOR, FERRITE BEAD
FB701 1-414-235-22 INDUCTOR, FERRITE BEAD
< IC >
IC201 8-759-492-59 IC SAA6588T/V2-118 (CA850)
IC202 8-759-909-71 IC BA4558F-E2 (CA850)
IC301 8-759-827-13 IC TDA7406T
IC302 8-759-826-90 IC NJM2160AV-TE2 (CA860X)
IC303 8-759-826-90 IC NJM2160AV-TE2 (CA860X)
IC304 8-759-832-29 IC NJM4580M-(TE2)
IC305 8-759-832-29 IC NJM4580M-(TE2)
IC308 8-759-100-96 IC uPC4558G2 (CA860X)
IC309 8-759-100-96 IC uPC4558G2 (CA860X)
IC310 8-759-198-34 IC TA75S558F(TE85R) (CA860X)
IC351 8-759-660-96 IC TDA7560 (CA860X)
IC351 8-759-827-14 IC TA8268AH (CA850/CA850X)
IC501 6-800-243-01 IC MB90574BPMT-G-335-BND (CA850)
IC501 8-759-837-48 IC MB90574BPMT-G-323-BND
(CA850X/CA860X)
IC502 8-759-828-22 IC XC61CN4102MR
IC601 8-759-449-89 IC BA8270F-E2
IC701 6-800-141-01 IC HD6432355A37F
IC702 8-759-277-63 IC TC7W14FU(TE12R)
IC801 8-759-460-80 IC BA10FP-E2 (CA860X)
< JACK >
J651 1-566-822-41 JACK (REMOTE IN) (CA850)
< COIL >
L101 1-419-476-11 COIL, CHOKE 250uH
L201 1-216-864-11 SHORT 0
L202 1-216-296-11 SHORT 0
< TRANSISTOR >
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q104 8-729-049-13 TRANSISTOR UPA1853GR-9JG-E1
Q105 8-729-421-22 TRANSISTOR UN2211
Q106 8-729-421-22 TRANSISTOR UN2211
Q201 8-729-106-60 TRANSISTOR 2SB1115A-YQ
Q202 8-729-421-22 TRANSISTOR UN2211
Q204 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (CA850)
Q205 8-729-421-22 TRANSISTOR UN2211 (CA850)
Q207 8-729-920-85 TRANSISTOR 2SD1664-QR
Q303 8-729-421-22 TRANSISTOR UN2211
Q304 8-729-424-08 TRANSISTOR UN2111
Q306 8-729-021-95 TRANSISTOR RN1441-A(TE85L) (CA860X)
Q306 8-729-920-21 TRANSISTOR DTC314TKH04 (CA850/CA850X)
Q307 8-729-021-95 TRANSISTOR RN1441-A(TE85L) (CA860X)
Q307 8-729-920-21 TRANSISTOR DTC314TKH04 (CA850/CA850X)
Q308 8-729-021-95 TRANSISTOR RN1441-A(TE85L) (CA860X)
Q308 8-729-920-21 TRANSISTOR DTC314TKH04 (CA850/CA850X)
Q309 8-729-021-95 TRANSISTOR RN1441-A(TE85L) (CA860X)
Q309 8-729-920-21 TRANSISTOR DTC314TKH04 (CA850/CA850X)
