59
CDX-CA850/CA850X/CA860X
R746 1-216-005-00 METAL CHIP 15 5% 1/10W
R747 1-216-005-00 METAL CHIP 15 5% 1/10W
R748 1-216-005-00 METAL CHIP 15 5% 1/10W
R749 1-216-005-00 METAL CHIP 15 5% 1/10W
R750 1-216-005-00 METAL CHIP 15 5% 1/10W
R801 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R802 1-216-833-11 METAL CHIP 10K 5% 1/16W
R803 1-216-821-11 METAL CHIP 1K 5% 1/16W
R804 1-216-817-11 METAL CHIP 470 5% 1/16W
R805 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R806 1-216-864-11 SHORT 0
R813 1-216-815-11 METAL CHIP 330 5% 1/16W
(CA860X)
< SWITCH >
S101 1-692-431-21 SWITCH, TACTILE (RESET)
S102 1-771-540-11 SWITCH, PUSH (1 KEY) (NOSE DET)
< THERMISTOR (POSITIVE) >
TH101 1-810-940-11 THERMISTOR, POSITIVE
TH102 1-810-940-11 THERMISTOR, POSITIVE
TH601 1-801-792-21 THERMISTOR, POSITIVE
< TUNER >
TUX201 A-3220-812-A TUNER UNIT (TUX-020)
< VIBRATOR >
X201 1-767-853-21 VIBRATOR, CRYSTAL (4.332MHz) (CA850)
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-767-833-21 VIBRATOR, CERAMIC (3.68MHz)
X701 1-781-822-21 VIBRATOR, CERAMIC (18.432MHz)
*************************************************************
* A-3326-231-A SERVO BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-115-156-11 CERAMIC CHIP 1uF 10V
C103 1-104-609-11 ELECT CHIP 100uF 20% 4V
C104 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C108 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C109 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
C115 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
C116 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C117 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
C118 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C127 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C301 1-126-393-11 ELECT CHIP 33uF 20% 10V
C302 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C303 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C304 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C305 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C306 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C307 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C308 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C309 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C310 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C311 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C312 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C501 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C502 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C504 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C505 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C506 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C508 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C509 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C510 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C511 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C512 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C513 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C514 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C515 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C516 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C517 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C518 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C519 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C520 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C521 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C522 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C550 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C553 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C554 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN1 1-764-616-12 HOUSING, CONNECTOR (PC BOARD) 30P
CN2 1-794-153-21 CONNECTOR, FPC (ZIF) 16P
CN3 1-770-347-21 CONNECTOR, FPC 6P
< JUMPER RESISTOR >
FB101 1-216-295-11 SHORT 0
FB102 1-216-295-11 SHORT 0
FB503 1-216-295-11 SHORT 0
< IC >
IC1 8-752-095-36 IC CXA2596M-T6
IC5 8-752-914-87 IC CXP84640-072Q
IC7 8-759-832-99 IC LA6576L-TE-L
IC501 8-752-392-04 IC CXD2598Q
< JUMPER RESISTOR >
JR501 1-216-295-11 SHORT 0
JR505 1-216-864-11 SHORT 0
SERVO
MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
