Sony CDX-L410 - CD Mechanism Section (2)

31
CDX-L410
4-4. CD MECHANISM SECTION (2)
(MG-393X-121//Q)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
151 X-3378-956-8 ARM ASSY, CHUCKING
152 3-931-897-61 DAMPER (T)
153 3-039-627-01 LEVER (D)
154 3-040-165-02 RETAINER (DISC)
155 3-018-272-01 WASHER
156 3-931-895-01 SPRING (CH), TENSION
157 3-931-898-01 SPRING (FL), COMPRESSION
158 3-032-483-02 SPRING (KF1), TENSION
159 A-3315-243-C CHASSIS (M) ASSY
160 3-220-180-01 SPRING (TR2), TENSION
161 3-931-881-03 LEVER (LOCK)
162 3-931-882-02 GEAR (MDL)
163 3-007-537-11 WHEEL (U), WORM
164 3-032-484-01 SPRING (KR1), TENSION
165 3-014-727-01 WHEEL (LW), WORM
166 3-039-626-01 LEVER (TR)
154
151
156
157
158
160
162
161
164
159
152
152
152
153
163
157
D
D
165
166
not supplied
155
155
