33
CDX-L410
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
KEYDISC IN
* 1-659-836-11 DISC IN BOARD
*************
< SWITCH >
SW1 1-529-566-31 SWITCH, PUSH (1 KEY) (DISC IN)
SW2 1-529-566-31 SWITCH, PUSH (1 KEY) (SELF)
*************************************************************
KEY BOARD
**********
1-694-781-11 CONDUCTIVE BOARD, CONNECTION
3-235-381-01 PLATE (LCD), LIGHT GUIDE
3-235-382-01 PLATE (LCD), GROUND
3-235-387-11 ILLUMINATOR (LCD)
3-235-388-01 REFLECTOR (LCD)
< CAPACITOR >
C991 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C992 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C993 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C994 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C995 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
< CONNECTOR >
CN901 1-794-312-11 PIN, CONNECTOR 12P
< DIODE >
D902 8-719-085-72 DIODE UMZ6.8ENTR
D991 8-719-976-99 DIODE DTZ5.1B
< IC >
IC901 8-759-365-90 IC LC75824W
< LIQUID CRYSTAL DISPLAY >
LCD901 1-804-625-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED921 8-719-038-07 LED CL-190PG-CD-T (DISC IND L) (GREEN)
LED921 8-719-047-66 LED CL-190D-CD-T (DISC IND L) (AMBER)
LED922 8-719-038-07 LED CL-190PG-CD-T (DISC IND R) (GREEN)
LED922 8-719-047-66 LED CL-190D-CD-T (DISC IND R) (AMBER)
< SWITCH >
LSW900 1-762-617-21 SWITCH, KEYBOARD (WITH LED) (Z) (AMBER)
LSW900 1-786-124-11 SWITCH, KEYBOARD (WITH LED) (Z) (GREEN)
LSW901 1-762-619-21 SWITCH, KEYBOARD (WITH LED) (OFF)
(GREEN)
LSW901 1-771-500-21 SWITCH, KEYBOARD (WITH LED) (OFF)
(AMBER)
LSW902 1-762-619-21 SWITCH, KEYBOARD (WITH LED)
(SRC (SOURCE)) (GREEN)
LSW902 1-771-500-21 SWITCH, KEYBOARD (WITH LED)
(SRC (SOURCE)) (AMBER)
LSW903 1-762-617-21 SWITCH, KEYBOARD (WITH LED) (+ (VOL))
(AMBER)
LSW903 1-786-124-11 SWITCH, KEYBOARD (WITH LED) (+ (VOL))
(GREEN)
LSW904 1-762-617-21 SWITCH, KEYBOARD (WITH LED) (– (VOL))
(AMBER)
LSW904 1-786-124-11 SWITCH, KEYBOARD (WITH LED) (– (VOL))
(GREEN)
LSW905 1-762-619-21 SWITCH, KEYBOARD (WITH LED) (MODE)
(GREEN)
LSW905 1-771-500-21 SWITCH, KEYBOARD (WITH LED) (MODE)
(AMBER)
LSW906 1-762-619-21 SWITCH, KEYBOARD (WITH LED) (SEL)
(GREEN)
LSW906 1-771-500-21 SWITCH, KEYBOARD (WITH LED) (SEL)
(AMBER)
LSW907 1-771-882-11 SWITCH, TACTILE (WITH LED) (ATT) (AMBER)
LSW907 1-786-113-11 SWITCH, TACTILE (WITH LED) (ATT) (GREEN)
LSW908 1-771-882-11 SWITCH, TACTILE (WITH LED) (SENS/BTM)
(AMBER)
LSW908 1-786-113-11 SWITCH, TACTILE (WITH LED) (SENS/BTM)
(GREEN)
LSW909 1-771-882-11 SWITCH, TACTILE (WITH LED) (AF) (AMBER)
LSW909 1-786-113-11 SWITCH, TACTILE (WITH LED) (AF) (GREEN)
LSW910 1-762-617-21 SWITCH, KEYBOARD (WITH LED)
(m . – (SEEK/AMS)) (AMBER)
LSW910 1-786-124-11 SWITCH, KEYBOARD (WITH LED)
(m . – (SEEK/AMS)) (GREEN)
LSW911 1-762-617-21 SWITCH, KEYBOARD (WITH LED)
(+ > M (SEEK/AMS)) (AMBER)
LSW911 1-786-124-11 SWITCH, KEYBOARD (WITH LED)
(+ > M (SEEK/AMS)) (GREEN)
LSW912 1-762-619-21 SWITCH, KEYBOARD (WITH LED) (MBP)
(GREEN)
LSW912 1-771-500-21 SWITCH, KEYBOARD (WITH LED) (MBP)
(AMBER)
LSW913 1-762-619-21 SWITCH, KEYBOARD (WITH LED) (D (D-BASS))
(GREEN)
To Next Page
