Sony CDX-L410 - Page 36

36
CDX-L410
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C805 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN701 1-794-311-21 PLUG, CONNECTOR 12P
CNP301 1-764-617-12 PIN, CONNECTOR (PC BOARD) 30P
CNP601 1-774-701-11 PIN, CONNECTOR 16P
< DIODE >
D21 8-719-404-50 DIODE MA111-TX
D22 8-719-404-50 DIODE MA111-TX
D23 8-719-976-99 DIODE DTZ5.1B
D331 8-719-056-84 DIODE UDZ-TE-17-7.5B
D332 8-719-056-83 DIODE UDZ-TE-17-6.8B
D341 8-719-158-15 DIODE RD5.6S-B
D471 8-719-053-18 DIODE 1SR154-400TE-25
D472 8-719-053-18 DIODE 1SR154-400TE-25
D473 8-719-053-18 DIODE 1SR154-400TE-25
D474 8-719-053-18 DIODE 1SR154-400TE-25
D475 8-719-053-18 DIODE 1SR154-400TE-25
D476 8-719-053-18 DIODE 1SR154-400TE-25
D477 8-719-053-18 DIODE 1SR154-400TE-25
D478 8-719-053-18 DIODE 1SR154-400TE-25
D479 8-719-404-50 DIODE MA111-TX
D480 8-719-158-15 DIODE RD5.6S-B
D551 8-719-056-84 DIODE UDZ-TE-17-7.5B
D556 8-719-057-80 DIODE MA8180-M-TX
D601 8-719-049-38 DIODE 1N5404TU
D609 8-719-056-83 DIODE UDZ-TE-17-6.8B
D610 8-719-056-65 DIODE 1SS372-TE85L
D613 8-719-053-18 DIODE 1SR154-400TE-25
D614 8-719-053-18 DIODE 1SR154-400TE-25
D621 8-719-067-56 DIODE MA112-TX
D651 8-719-057-80 DIODE MA8180-M-TX
D671 8-719-404-50 DIODE MA111-TX
D701 8-719-404-50 DIODE MA111-TX
D710 8-719-056-83 DIODE UDZ-TE-17-6.8B
D711 8-719-056-83 DIODE UDZ-TE-17-6.8B
D715 8-719-056-83 DIODE UDZ-TE-17-6.8B
D716 8-719-056-83 DIODE UDZ-TE-17-6.8B
D717 8-719-056-83 DIODE UDZ-TE-17-6.8B
D718 8-719-056-83 DIODE UDZ-TE-17-6.8B
< IC >
IC20 8-759-100-96 IC uPC4558G2
IC51 8-759-492-59 IC SAA6588T-118
IC401 8-759-653-27 IC TDA7402TR
IC404 8-759-486-44 IC TDA7386
IC501 6-800-278-02 IC MN101C49KTD2
IC601 8-759-661-47 IC BA4908-V3
IC602 8-759-682-69 IC XC61CN4302MR
< JACK >
J10 1-815-185-12 JACK (ANTENNA)
J561 1-566-822-41 JACK (REMOTE IN)
< COIL >
L500 1-419-476-11 COIL, CHOKE 250uH
< TRANSISTOR >
Q21 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q22 8-729-900-53 TRANSISTOR DTC114EK
Q331 8-729-021-82 TRANSISTOR 2SD2396K
Q332 8-729-047-76 TRANSISTOR FMC2A-T148
Q333 8-729-900-53 TRANSISTOR DTC114EK
Q341 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q431 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q441 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q451 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q461 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q478 8-729-900-53 TRANSISTOR DTC114EK
Q479 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q551 8-729-900-53 TRANSISTOR DTC114EK
Q556 8-729-900-53 TRANSISTOR DTC114EK
Q557 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q631 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q651 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q661 8-729-821-63 TRANSISTOR 2SB1203T-FA
Q662 8-729-900-53 TRANSISTOR DTC114EK
Q664 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R21 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R22 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R24 1-216-833-11 METAL CHIP 10K 5% 1/16W
R25 1-216-833-11 METAL CHIP 10K 5% 1/16W
R26 1-216-809-11 METAL CHIP 100 5% 1/16W
R27 1-216-845-11 METAL CHIP 100K 5% 1/16W
R28 1-216-857-11 METAL CHIP 1M 5% 1/16W
R29 1-216-809-11 METAL CHIP 100 5% 1/16W
R31 1-218-867-11 RES-CHIP 6.8K 5% 1/16W
R32 1-216-845-11 METAL CHIP 100K 5% 1/16W
R41 1-216-841-11 METAL CHIP 47K 5% 1/16W
R52 1-216-853-11 METAL CHIP 470K 5% 1/16W
R53 1-216-821-11 METAL CHIP 1K 5% 1/16W
R54 1-216-837-11 METAL CHIP 22K 5% 1/16W
R56 1-216-797-11 METAL CHIP 10 5% 1/16W
R57 1-216-817-11 METAL CHIP 470 5% 1/16W
R60 1-216-797-11 METAL CHIP 10 5% 1/16W
R331 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R332 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R333 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R334 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R341 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
