Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C11 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C13 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C14 1-125-837-00 CERAMIC CHIP 1uF 10% 6.3V
C15 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C16 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C19 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C21 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C22 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C23 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C24 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C25 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C26 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C27 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C28 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C29 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C30 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C31 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C34 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C35 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C36 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C37 1-126-393-11 ELECT CHIP 33uF 20% 10V
C38 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C39 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C40 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C41 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C43 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C44 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN1 1-764-616-12 HOUSING, CONNECTOR (PC BOARD) 30P
CN2 1-794-153-21 CONNECTOR, FPC (ZIF) 16P
CN3 1-770-347-21 CONNECTOR, FPC 6P
< JUMPER RESISTOR >
FB1 1-216-864-11 METAL CHIP 0 5% 1/16W
FB2 1-216-864-11 METAL CHIP 0 5% 1/16W
FB4 1-216-864-11 METAL CHIP 0 5% 1/16W
FB5 1-216-295-11 SHORT 0
FB6 1-216-864-11 METAL CHIP 0 5% 1/16W
FB7 1-216-864-11 METAL CHIP 0 5% 1/16W
< IC >
IC1 8-759-699-98 IC uPD63711GC-8EU
IC2 8-759-658-87 IC BA5810FP-E2
< TRANSISTOR >
Q1 8-729-904-87 TRANSISTOR 2SB1197K-R
< RESISTOR >
R3 1-216-797-11 METAL CHIP 10 5% 1/16W
R5 1-218-344-11 RES-CHIP 7.5K 5% 1/16W
R6 1-216-837-11 METAL CHIP 22K 5% 1/16W
R7 1-216-839-11 METAL CHIP 33K 5% 1/16W
R8 1-216-833-11 METAL CHIP 10K 5% 1/16W
R9 1-216-840-11 METAL CHIP 39K 5% 1/16W
R10 1-216-835-11 METAL CHIP 15K 5% 1/16W
R12 1-216-837-11 METAL CHIP 22K 5% 1/16W
R14 1-216-841-11 METAL CHIP 47K 5% 1/16W
R15 1-216-841-11 METAL CHIP 47K 5% 1/16W
R17 1-216-809-11 METAL CHIP 100 5% 1/16W
R18 1-216-809-11 METAL CHIP 100 5% 1/16W
R19 1-216-809-11 METAL CHIP 100 5% 1/16W
R20 1-216-809-11 METAL CHIP 100 5% 1/16W
R21 1-216-821-11 METAL CHIP 1K 5% 1/16W
R22 1-216-821-11 METAL CHIP 1K 5% 1/16W
R24 1-216-864-11 METAL CHIP 0 5% 1/16W
R25 1-216-864-11 METAL CHIP 0 5% 1/16W
R26 1-216-797-11 METAL CHIP 10 5% 1/16W
R29 1-216-833-11 METAL CHIP 10K 5% 1/16W
R30 1-216-833-11 METAL CHIP 10K 5% 1/16W
R31 1-216-789-11 METAL CHIP 2.2 5% 1/16W
< VIBRATOR >
X1 1-781-759-21 VIBRATOR, CERAMIC (CHIP TYPE)
(16.9344MHz)
*************************************************************
* 1-659-834-11 SUB BOARD
**********
< CONNECTOR >
CN1 1-770-347-21 CONNECTOR, FPC 6P
*************************************************************
MISCELLANEOUS
***************
5 1-776-527-82 CORD (WITH CONNECTOR) (ISO) (POWER)
201 X-3378-598-2 CHASSIS (OP) ASSY (including M901)
207 1-659-880-11 MOTOR FLEXIBLE BOARD
0 210 8-820-103-11 PICK-UP, OPTICAL KSS-720A/C-RP
212 1-676-707-21 PICK-UP FLEXIBLE BOARD
F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A
M902 A-3291-674-A MOTOR ASSY, SLED (SLED)
M903 A-3315-039-A MOTOR SUB ASSY, LD (LOADING)
*************************************************************
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
SERVO SUB
