SECTION 5
ELECTRICAL PARTS LIST
CDX-MP30
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
A-3274-253-A DISC IN SW BOARD, COMPLETE
**************************
< SWITCH >
SW2 1-529-566-31 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-31 SWITCH, PUSH (1 KEY) (DISC IN)
************************************************************
DISPLAY BOARD
**************
* 3-227-293-01 SHEET (LCD)
* 3-229-751-01 SHEET (LCD.UP)
3-236-920-01 SHEET (LCD), DIFFUSION
3-236-921-01 PLATE (LCD), GROUND
< CAPACITOR >
C501 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C502 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CNP551 1-779-131-11 PIN, CONNECTOR 2P
CNP552 1-794-312-21 PIN, CONNECTOR 12P
< DIODE >
D501 8-719-068-68 DIODE SDZ6V2WA
D502 8-719-069-56 DIODE UDZSTE-176.2B
D503 8-719-073-15 DIODE SDZ5V1
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-069-54 DIODE UDZSTE-175.1B
D561 8-719-053-09 DIODE SML-310VTT86 (OFF)
D562 8-719-053-09 DIODE SML-310VTT86 (TA) (AEP, E)
D563 8-719-053-09 DIODE SML-310VTT86 (SENS/BTM)
D564 8-719-053-09 DIODE SML-310VTT86 (SEEK4)
D565 8-719-053-09 DIODE SML-310VTT86 (SEEK5)
D566 8-719-053-09 DIODE SML-310VTT86 (Z)
D567 8-719-053-09 DIODE SML-310VTT86 (SEEK3)
D568 8-719-053-09 DIODE SML-310VTT86 (D-BASS)
D569 8-719-053-09 DIODE SML-310VTT86 (SEEK1)
D570 8-719-053-09 DIODE SML-310VTT86 (SEEK2)
D571 8-719-053-09 DIODE SML-310VTT86 (LIST/PTY)
D572 8-719-053-09 DIODE SML-310VTT86 (MBP)
D573 8-719-053-09 DIODE SML-310VTT86 (4/SHUFF)
D574 8-719-053-09 DIODE SML-310VTT86 (5/ALBUM-)
D575 8-719-053-09 DIODE SML-310VTT86 (6/ALBUM+)
D576 8-719-053-09 DIODE SML-310VTT86 (3/REP)
D577 8-719-053-09 DIODE SML-310VTT86 (2/DISC+)
D578 8-719-053-09 DIODE SML-310VTT86 (1/DISC-)
D579 8-719-053-09 DIODE SML-310VTT86 (ATT)
D580 8-719-053-09 DIODE SML-310VTT86 (AF) (AEP, E)
D581 8-719-053-09 DIODE SML-310VTT86 (DSPL)
D582 8-719-053-09 DIODE SML-310VTT86 (VOL2)
D583 8-719-053-09 DIODE SML-310VTT86 (VOL1)
D584 8-719-053-09 DIODE SML-310VTT86 (MODE)
D585 8-719-053-09 DIODE SML-310VTT86 (SOURCE)
D586 8-719-053-09 DIODE SML-310VTT86 (VOL5)
D587 8-719-053-09 DIODE SML-310VTT86 (SEL)
D588 8-719-053-09 DIODE SML-310VTT86 (VOL4)
D589 8-719-053-09 DIODE SML-310VTT86 (VOL3)
< IC >
IC501 8-759-366-34 IC LC75824E
IC552 8-749-017-35 IC KSM-401N (g)
< JUMPER RESISTOR >
JR501 1-216-864-11 METAL CHIP 0 5% 1/16W
JR502 1-216-864-11 METAL CHIP 0 5% 1/16W
JR503 1-216-864-11 METAL CHIP 0 5% 1/16W
JR504 1-216-864-11 METAL CHIP 0 5% 1/16W
JR505 1-216-864-11 METAL CHIP 0 5% 1/16W
JR506 1-216-864-11 METAL CHIP 0 5% 1/16W
JR507 1-216-864-11 METAL CHIP 0 5% 1/16W
(US)
JR508 1-216-864-11 METAL CHIP 0 5% 1/16W
(US)
JR509 1-216-295-91 SHORT 0
< LIQUID CRYSTAL DISPLAY >
LCD501 1-804-693-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED549 6-500-083-01 DIODE NSPW315BSRS (LCD BACK LIGHT)
LED550 6-500-083-01 DIODE NSPW315BSRS (LCD BACK LIGHT)
< RESISTOR >
R501 1-219-286-11 RES-CHIP 680 2% 1/16W
R502 1-219-286-11 RES-CHIP 680 2% 1/16W
R503 1-219-286-11 RES-CHIP 680 2% 1/16W
R504 1-218-847-11 RES-CHIP 1K 2% 1/16W
R505 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
