Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
52
CFD-E75L
L290 1-414-142-61 INDUCTOR 1uH
L391 1-414-142-61 INDUCTOR 1uH
< TRANSISTOR >
Q191 8-729-036-89 TRANSISTOR KTC3198GR-A
Q291 8-729-036-89 TRANSISTOR KTC3198GR-A
Q390 8-729-052-52 TRANSISTOR KTC2026Y
Q391 8-729-052-52 TRANSISTOR KTC2026Y
Q392 8-729-037-13 TRANSISTOR KTA1271Y
Q393 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R190 1-216-813-11 METAL CHIP 220 5% 1/16W
R191 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R193 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R194 1-216-809-11 METAL CHIP 100 5% 1/16W
R196 1-216-817-11 METAL CHIP 470 5% 1/16W
R197 1-216-835-11 METAL CHIP 15K 5% 1/16W
R198 1-216-821-11 METAL CHIP 1K 5% 1/16W
R290 1-216-813-11 METAL CHIP 220 5% 1/16W
R291 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R293 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R294 1-216-809-11 METAL CHIP 100 5% 1/16W
R296 1-216-817-11 METAL CHIP 470 5% 1/16W
R297 1-216-835-11 METAL CHIP 15K 5% 1/16W
R298 1-216-821-11 METAL CHIP 1K 5% 1/16W
R390 1-216-805-11 METAL CHIP 47 5% 1/16W
R391 1-216-809-11 METAL CHIP 100 5% 1/16W
R392 1-216-811-11 METAL CHIP 150 5% 1/16W
R393 1-216-797-11 METAL CHIP 10 5% 1/16W
R394 1-249-407-11 CARBON 150 5% 1/4W
R395 1-216-821-11 METAL CHIP 1K 5% 1/16W
R396 1-216-841-11 METAL CHIP 47K 5% 1/16W
R397 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R398 1-216-853-11 METAL CHIP 470K 5% 1/16W
R901 1-216-809-11 METAL CHIP 100 5% 1/16W
R902 1-216-809-11 METAL CHIP 100 5% 1/16W
0 R903 1-219-149-11 FUSIBLE 1 5% 1/4W F
< TRANSFORMER >
0 T901 1-437-320-11 TRANSFORMER, POWER
**************************************************************
* A-3347-189-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-104-664-11 ELECT 47uF 20% 10V
C103 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C104 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C105 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C106 1-126-960-11 ELECT 1uF 20% 50V
C107 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-104-664-11 ELECT 47uF 20% 10V
C203 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C204 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C205 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20% 50V
C207 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C301 1-104-665-11 ELECT 100uF 20% 10V
C302 1-104-665-11 ELECT 100uF 20% 10V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-104-664-11 ELECT 47uF 20% 10V
C305 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C308 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C310 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CNP301 1-784-774-11 CONNECTOR, FFC 13P
< IC >
IC301 8-759-264-71 IC TA2068N
< RESISTOR >
JC301 1-216-864-11 METAL CHIP 0 5% 1/16W
JC302 1-216-864-11 METAL CHIP 0 5% 1/16W
JC303 1-216-864-11 METAL CHIP 0 5% 1/16W
JC304 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-835-11 METAL CHIP 15K 5% 1/16W
R102 1-216-807-11 METAL CHIP 68 5% 1/16W
R103 1-216-843-11 METAL CHIP 68K 5% 1/16W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R105 1-216-835-11 METAL CHIP 15K 5% 1/16W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R110 1-216-809-11 METAL CHIP 100 5% 1/16W
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R201 1-216-835-11 METAL CHIP 15K 5% 1/16W
R202 1-216-807-11 METAL CHIP 68 5% 1/16W
R203 1-216-843-11 METAL CHIP 68K 5% 1/16W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R205 1-216-835-11 METAL CHIP 15K 5% 1/16W
R206 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R210 1-216-025-11 RES-CHIP 100 5% 1/10W
R211 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R301 1-216-857-11 METAL CHIP 1M 5% 1/16W
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R304 1-216-821-11 METAL CHIP 1K 5% 1/16W
R305 1-216-811-11 METAL CHIP 150 5% 1/16W
R306 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R307 1-216-799-11 METAL CHIP 15 5% 1/16W
R308 1-216-837-11 METAL CHIP 22K 5% 1/16W
R309 1-216-805-11 METAL CHIP 47 5% 1/16W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER TC
