Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
54
CFD-E75L
JC34 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L1 1-409-775-11 COIL, AIR-CORE
L2 1-416-509-11 COIL, AIR-CORE
L3 1-754-116-11 ANTENNA, FERRITE-ROD (LW MW)
L4 1-411-199-31 COIL, MW/LW OSC
L21 1-410-509-61 INDUCTOR 10uH
< TRANSISTOR >
Q12 8-729-028-99 TRANSISTOR DTC114YUA-T106
Q14 8-729-905-35 TRANSISTOR 2SC4081-R
Q41 8-729-920-31 TRANSISTOR DTC343TK
Q42 8-729-054-77 TRANSISTOR 2SC4098-T106-PQ
Q43 8-729-920-38 TRANSISTOR 2SC2059K-N
Q44 8-729-054-77 TRANSISTOR 2SC4098-T106-PQ
Q61 8-729-106-07 FET 2SK514-H
< RESISTOR >
R1 1-216-817-11 METAL CHIP 470 5% 1/16W
R2 1-216-817-11 METAL CHIP 470 5% 1/16W
R3 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4 1-216-833-11 METAL CHIP 10K 5% 1/16W
R7 1-216-853-11 METAL CHIP 470K 5% 1/16W
R9 1-216-845-11 METAL CHIP 100K 5% 1/16W
R10 1-216-805-11 METAL CHIP 47 5% 1/16W
R11 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R12 1-216-841-11 METAL CHIP 47K 5% 1/16W
R13 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R16 1-216-833-11 METAL CHIP 10K 5% 1/16W
R17 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R18 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R19 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R22 1-216-833-11 METAL CHIP 10K 5% 1/16W
R24 1-216-813-11 METAL CHIP 220 5% 1/16W
R30 1-216-835-11 METAL CHIP 15K 5% 1/16W
R31 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R32 1-216-845-11 METAL CHIP 100K 5% 1/16W
R40 1-216-853-11 METAL CHIP 470K 5% 1/16W
R41 1-216-833-11 METAL CHIP 10K 5% 1/16W
R42 1-216-845-11 METAL CHIP 100K 5% 1/16W
R43 1-216-833-11 METAL CHIP 10K 5% 1/16W
R50 1-216-821-11 METAL CHIP 1K 5% 1/16W
R51 1-216-833-11 METAL CHIP 10K 5% 1/16W
R52 1-216-809-11 METAL CHIP 100 5% 1/16W
R53 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R54 1-216-817-11 METAL CHIP 470 5% 1/16W
R56 1-216-815-11 METAL CHIP 330 5% 1/16W
R58 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R59 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R60 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R61 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R63 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R64 1-216-821-11 METAL CHIP 1K 5% 1/16W
R66 1-216-805-11 METAL CHIP 47 5% 1/16W
R91 1-216-821-11 METAL CHIP 1K 5% 1/16W
R92 1-216-821-11 METAL CHIP 1K 5% 1/16W
R93 1-216-821-11 METAL CHIP 1K 5% 1/16W
R94 1-216-821-11 METAL CHIP 1K 5% 1/16W
< TRANSFORMER >
T1 1-433-741-11 TRANSFORMER, IF
T2 1-419-465-11 COIL (DET)
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
**************************************************************
MISCELLANEOUS
**************
8 1-452-899-11 MAGNET
71 1-792-684-11 WIRE (FLAT TYPE) (16 CORE)
* 72 1-757-968-11 FFC CABLE 14P
101 1-757-967-11 FFC CABLE 27P
* 111 1-757-969-11 FFC CABLE 13P
0 501 8-848-483-05 OPTICAL PICK-UP DEVICE (KSS-213C)
ANT1 1-754-191-11 ANTENNA, TELESCOPIC
HE301 1-543-876-14 HEAD (ERASE)
HRP301 1-500-668-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
LCD801 1-804-401-11 DISPLAY PANEL, LIQUID CRYSTAL
M301 A-3320-446-A MOTOR ASSY (WITH PULLEY)
(CAPSTAN/REEL)
M702 X-2625-769-1 GERA ASSY (MB), MOTOR (SLED)
S303 1-762-679-11 SWITCH, LEAF (MOTOR ON/OFF)
S304 1-771-059-11 SWITCH, LEAF (TAPE PLAY)
S901 1-692-960-11 SWITCH, PUSH (1 KEY) (CD LID OPEN/CLOSE)
0 T901 1-437-320-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-14 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-649-79 SCREW +BVTP 3X14 TYPE2 N-S
#3 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#4 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#5 7-685-853-04 SCREW +BVTT 2X6 (S)
#6 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#7 7-682-548-04 SCREW +B 3X8
#8 7-685-903-31 SCREW +PTPWH 3X10 (TYPE2)
#9 7-621-770-87 SCREW +B 2.6X5
#10 7-685-783-09 SCREW +PTT 2X6 (S)
************************************************************
TUNER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
