Sony CFD-G55 - BATT COM, BATT Board; MAIN Board- 1

10
CFD-G55
3-10. BATT COM, BATT Board
3-11. MAIN Board- 1
1 CNP902
(from BATT board KH951)
5 screw
3 × 8 (DIA, 10),+W
H
6 BATT COM board
9 battery
terminal
8 battery termina
l
4 BATT board
7 four screws
+BVTP 3 × 10
3 screw
3 × 8 (DIA, 10),+WH
2 Remove harnesses in the direction
of the arrow.
BATT board
9 four screws
+BVTP 3
× 10
3 CD door sw
(S801)
4 CNP351
qs MAIN board
!¡ hook
8 CNP371
7 CNP37
2
6 CNP373
5 CNP352
0 CNP302
1 flexible flat cable
CNP805
2 flexible flat cable
CNP802
L-R/REG board
PDW board
qs
