Sony CFD-G55 - CD Block Section (KSM-213 RDP); PDW, L-R;REG Board

12
CFD-G55
3-14. CD Block Section
(KSM-213RDP)
3-15. PDW, L-R/REG Board
1 screw
+BVTP 3 × 10
3 two screws
+BVTP 3
× 10
4 L-R/REG board,
chassis (HS, L)
2 clamp
5 three screws
+BVTP 3 × 10
6 PDW board,
Chassis (HS, R)
4 CD board
3 flexible flat cable
CNP701
2 Remove solderings
from the four points.
1 flexible flat cable
(from MAIN board CNP802
)
6 CD block section
(KSM-213RDP)
5 four screws
+PWH 2.6
× 10
