Sony CFS-B5SMK2

– 24 –
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the par ts list ma y be different from the
par ts specified in the diag rams or the
components used on the set.
• -XX and -X mean standardized parts, so
the y ma y ha ve some diff erence from the
original one.
• RESIST ORS
All resistors are in ohms.
METAL:Metal-film resistor .
METAL OXIDE: Metal o xide-film resistor .
F:nonflammable
• Items mar ked “*” are not stoc ked since
the y are seldom required f or routine ser vice.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCT ORS
In each case , u : µ, for e xample:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified b y
mark ! or dotted line with mark.
! are cr itical for saf ety.
Replace only with part number
specified.
When indicating parts by reference
number , please include the board.
• Abbre viation
EA : Saudi Ar abia model
E15 : AC 220-240V Area model
* 1-670-178-11 AC BOARD
*********
1-533-233-31 HOLDER, FUSE
< CAP ACIT OR >
C909 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CN901 1-691-573-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
! F901 1-532-149-31 FUSE, TIME-LAG (T0.125AL/250V)
< AC INLET >
! J901 1-526-838-11 INLET , A C 2P ( ⁄ A C IN)
< SWITCH >
! S901 1-552-921-00 SWITCH, PO WER (V OL T A GE CHANGE)
(V OLTA GE SELECT OR)
*************************************************************
* A-3321-464-A AUDIO BOARD, COMPLETE
**********************
< CAP ACIT OR >
C101 1-124-903-11 ELECT 1uF 20% 50V
C102 1-162-294-31 CERAMIC 0.001uF 10% 50V
C103 1-124-443-00 ELECT 100uF 20 % 10V
C104 1-162-843-11 CERAMIC 0.022uF 10% 16V
C105 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C111 1-126-956-11 ELECT 0.1uF 20% 50V
C115 1-126-958-11 ELECT 0.33uF 20% 50V
C116 1-162-306-11 CERAMIC 0.01uF 20% 16V
C151 1-136-160-00 FILM 0.039uF 5% 50V
C152 1-136-165-00 FILM 0.1uF 5% 50V
C191 1-124-473-11 ELECT 1000uF 20% 10V
C197 1-136-165-00 FILM 0.1uF 5% 50V
C201 1-124-903-11 ELECT 1uF 20% 50V
C202 1-162-294-31 CERAMIC 0.001uF 10% 50V
C203 1-124-443-00 ELECT 100uF 20 % 10V
C204 1-162-843-11 CERAMIC 0.022uF 10% 16V
C205 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C211 1-126-956-11 ELECT 0.1uF 20 % 50V
C215 1-126-958-11 ELECT 0.33uF 20% 50V
C216 1-162-306-11 CERAMIC 0.01uF 20% 16V
C251 1-136-160-00 FILM 0.039uF 5% 50V
C252 1-136-165-00 FILM 0.1uF 5% 50V
C291 1-124-473-11 ELECT 1000uF 20% 10V
C297 1-136-165-00 FILM 0.1uF 5% 50V
C301 1-126-941-11 ELECT 470uF 20 % 16V
C302 1-104-664-11 ELECT 47uF 2 0 % 10V
C304 1-162-294-31 CERAMIC 0.001uF 10% 50V
C306 1-124-907-11 ELECT 10uF 2 0 % 50V
C311 1-161-494-00 CERAMIC 0.022uF 25V
C312 1-161-494-00 CERAMIC 0.022uF 25V
C315 1-124-907-11 ELECT 10uF 2 0 % 50V
C340 1-162-294-31 CERAMIC 0.001uF 10% 50V
C342 1-130-481-00 MYLAR 0.0068uF 5% 50V
C344 1-104-664-11 ELECT 47uF 2 0 % 10V
C351 1-124-907-11 ELECT 10uF 2 0 % 50V
C352 1-126-233-11 ELECT 22uF 2 0 % 50V
C353 1-124-443-00 ELECT 100uF 20 % 10V
C391 1-104-666-11 ELECT 220uF 20 % 10V
C392 1-162-294-31 CERAMIC 0.001uF 10% 50V
C393 1-126-961-11 ELECT 2.2uF 20 % 50V
C394 1-162-294-31 CERAMIC 0.001uF 10% 50V
C395 1-162-294-31 CERAMIC 0.001uF 10% 50V
C396 1-124-902-00 ELECT 0.47uF 20% 50V
C910 1-126-944-11 ELECT 3300uF 20% 16V
C911 1-162-294-31 CERAMIC 0.001uF 10% 50V
C914 1-136-683-11 FILM 0.0056uF 5% 100V
C951 1-162-306-11 CERAMIC 0.01uF 20% 16V
C952 1-104-664-11 ELECT 47uF 2 0 % 10V
C953 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN301 1-691-575-11 PIN, CONNECTOR (PC BOARD) 4P
CN305 1-568-271-11 PIN, CONNECTOR (PC BOARD) 5P
CN601 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
* CN911 1-691-573-11 PIN, CONNECTOR (PC BOARD) 2P
CN912 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
* CN913 1-573-287-11 HOLDER, CABLE 2P
AC AUDIO
