Sony CFS-B5SMK2

– 26 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-670-173-11 SECOND BOARD
**************
< CAP ACIT OR >
C901 1-101-005-00 CERAMIC 0.022uF 50V
C902 1-101-005-00 CERAMIC 0.022uF 50V
C903 1-101-005-00 CERAMIC 0.022uF 50V
C904 1-101-005-00 CERAMIC 0.022uF 50V
C905 1-136-165-00 FILM 0.1uF 5% 50V
C906 1-136-165-00 FILM 0.1uF 5% 50V
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
< RESISTOR >
R919 1-249-421-11 CARBON 2.2K 5% 1/4W
*************************************************************
* 1-670-179-11 SUPPOR T BO ARD
***************
*************************************************************
* A-3321-465-A TUNER BOARD, COMPLETE (EXCEPT EA)
* A-3321-471-A TUNER BOARD, COMPLETE (EA)
**********************
< CAP ACIT OR >
C1 1-162-286-31 CERAMIC 220PF 10 % 50V
C2 1-162-215-31 CERAMIC 47PF 5% 50V
C3 1-162-306-11 CERAMIC 0.01uF 20% 16V
C4 1-104-664-11 ELECT 47uF 2 0 % 10 V
C5 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6 1-162-204-31 CERAMIC 16PF 5% 50V
(EXCEPT EA)
C6 1-162-207-31 CERAMIC 22PF 5% 50V
(EA)
C8 1-102-959-00 CERAMIC 22PF 5% 50V
(EXCEPT EA)
C8 1-102-961-00 CERAMIC 27PF 5% 50V
(EA)
C10 1-162-193-31 CERAMIC 3.3PF 10% 50V
C11 1-162-306-11 CERAMIC 0.01uF 20% 16V
C14 1-162-282-31 CERAMIC 100PF 1 0% 50V
C15 1-126-963-11 ELECT 4.7uF 2 0% 50V
C16 1-124-903-11 ELECT 1uF 20% 50V
C17 1-124-907-11 ELECT 10uF 2 0% 50 V
C18 1-124-907-11 ELECT 10uF 2 0% 50 V
C19 1-162-306-11 CERAMIC 0.01uF 20% 16V
C20 1-124-903-11 ELECT 1uF 20% 50V
C21 1-126-961-11 ELECT 2.2uF 2 0% 50V
C22 1-124-443-00 ELECT 100uF 2 0% 10V
C23 1-124-902-00 ELECT 0.47uF 20% 50V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C25 1-126-956-11 ELECT 0.1uF 20% 50V
C26 1-162-203-31 CERAMIC 15PF 5% 50V
C27 1-161-050-00 CERAMIC 0.0082uF 10% 16V
C28 1-161-050-00 CERAMIC 0.0082uF 10% 16V
C29 1-162-282-31 CERAMIC 100PF 10 % 50V
C30 1-162-282-31 CERAMIC 100PF 10 % 50V
C32 1-162-198-31 CERAMIC 8.2PF 10% 50V
C35 1-162-282-31 CERAMIC 100PF 10 % 50V
C36 1-164-617-11 CERAMIC 4PF 5% 5 0V
C38 1-162-202-31 CERAMIC 13PF 5% 50V
(EXCEPT EA)
C38 1-162-205-31 CERAMIC 18PF 5% 50V
(EA)
C39 1-164-617-11 CERAMIC 4PF 5% 5 0V
C40 1-136-480-11 FILM 0.0015uF 5% 100V
C41 1-107-734-11 FILM 360PF 5% 100V
C42 1-136-683-11 FILM 0.0056uF 5% 100V
C46 1-162-282-31 CERAMIC 100PF 10 % 50V
C47 1-162-282-31 CERAMIC 100PF 10 % 50V
C50 1-162-282-31 CERAMIC 100PF 10 % 50V
C51 1-162-294-31 CERAMIC 0.001uF 10% 50V
C52 1-162-202-31 CERAMIC 13PF 5% 50V
C53 1-162-287-31 CERAMIC 270PF 10 % 50V
C71 1-162-306-11 CERAMIC 0.01uF 20% 16V
< FIL TER >
CF1 1-760-738-61 FIL TER, CERAMIC
CF2 1-567-670-11 FIL TER, CERAMIC
< CONNECTOR >
CN1 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< V ARIABLE CAP ACIT OR >
CT1-4 1-151-693-11 CAP , VAR
CV1-4 1-151-693-11 CAP , VAR (TUNING)
< TRIMMER >
CT6 1-141-485-11 CAP , ADJ 5PF
CT8 1-141-485-11 CAP , ADJ 5PF
< DIODE >
D1 8-719-911-19 DIODE 1SS119
D2 8-719-911-19 DIODE 1SS119
D3 8-719-911-19 DIODE 1SS119
< IC >
IC1 8-752-050-20 IC CXA1238S
TUNER
SUPPORT
SECOND
