Sony D-FS601 - MD Assy (CDM-3125 ER), MAIN Board; Turn Table Motor Assy (Spindle) (M901)

7
D-FS601
5
7
4
6
RV301
cabinet lower sub assy
MD ASSY (CDM-3125ER)
MAIN board
lever(vol)(B)
3 connector (CN502)(black)
2 connector (CN503)(white)
1 flexible cable (15P)
3-2. MD Assy (CDM-3125ER), MAIN Board
3-3. Turn Table Motor Assy (Spindle) (M901)
2
turn table motor ass
y
(spindle) (M901)
1 three screws
(B1.7x5)
chassis
