172
Identifying the parts and controls
qa > MEMORY EJECT Lever
(DCR-TRV17 only) (p. 105)
qs Power zoom lever (p. 24)
qd POWER switch (p. 13)
qf
qg
qh
qj
qs
qa
qd
Notes on the intelligent accessory shoe
•The intelligent accessory shoe supplies power to optional accessories such as a video
light, microphone or printer (DCR-TRV17 only) .
•The intelligent accessory shoe is linked to the POWER switch, allowing you to turn the
power supplied by the shoe on and off. Refer to the operating instructions of the
accessory for further information.
•The intelligent accessory shoe has a safety device for fixing the installed accessory
securely. To connect an accessory, press down and push it to the end, and then tighten
the screw.
•To remove an accessory, loosen the screw, and then press down and pull out the
accessory.
qf EDITSEARCH button (p. 30)
qg SUPER LASER LINK button (p. 36)
qh Intelligent accessory shoe (p. 85)
qj Camera recording lamp (p. 21)
