208
wk PHOTO button (p. 45, 106, 110)
wl Power zoom lever (p. 32, 70, 129)
e; Stylus holder (DCR-TRV39 only)
(p. 166)
ea Stylus (DCR-TRV39 only) (p. 166)
Identifying parts and controls
Notes on the intelligent accessory shoe
The intelligent accessory shoe supplies power to optional accessories such as a video
light or microphone.
The intelligent accessory shoe is linked to the POWER switch, allowing you to turn the
power supplied by the shoe on and off. Refer to the operating instructions of the
accessory for details.
The intelligent accessory shoe has a safety device for fixing the installed accessory
securely. To connect an accessory, press down and push it to the end, and then tighten
the screw.
To remove an accessory, loosen the screw, and then press down and pull out the
accessory.
es EDITSEARCH button (p. 36)
ed Intelligent accessory shoe (p. 91)
ef NIGHTSHOT switch (p. 33)
eg Grip belt
eg
es
wk
ef
ed
e;
wl
ea
