Appendixes
Appendixes A-65
Output signals
PGM OUT
SDI BNC type × 2
270 Mb/s, compliant with SMPTE-
259M
COMPONENT BNC type (Y/R–Y/B–Y ) × 2
Y: 1.0 Vp-p, 75 ohms, sync
negagive
R–Y/B–Y: 0.756 Vp-p, 75 ohms
COMPOSITE BNC type × 2
Video: 1.0 Vp-p, 75 ohms,
sync negative
S-VIDEO DIN × 2
Y: 1.0 Vp-p, 75 ohms, sync
negative
C (BURST): 0.286 Vp-p, 75 ohms
CLEAN OUT BNC type × 1
SDI: 270 Mb/s, compliant with
SMPTE-259M
BLACK BURST OUT
BNC type × 3
SYNC: 0.286 Vp-p
BURST: 0.286 Vp-p
Control signals
EDITOR D-sub, 9-pin × 1 (RS-422A)
GPI T 1/2 BNC type × 2, TTL level, active
low
PANEL D-sub, 25-pin × 1
TALLYL D-sub, 25-pin × 1, relay contact
output × 8
TERMINAL USB × 1
Recommended equipment and cables
Editing control unit
PVE-500, BVE-900/910/2000,
BVE-600
VTR DSR-2000/2000P, DNW-75/75P
Audio mixer SRP-V200R
Cables RCC-5G/10G/30G 9-pin remote
control cables
Supplied accessories
AC power cord (1)
25-pin control cable, 10 m (1)
Button labels (1 set)
Tool for removing key tops (1)
Operation manual (1)
Design and specifications subject to change without
notice.
