4 Press YES to load the selected Title, or press CANCEL to abort the operation. Note that the DMX-
R100 will reboot if the Title being loaded utilizes a different sample rate or clock source than the
currently selected Title.
TIP: Because each Title is time- and date-stamped, you can identify the latest version saved even if you neglect
to give each Title a distinct name.
To load (recall) a previously stored Title, follow this procedure.
1 If loading from floppy disk, insert it into the DMX-R100 disk drive, and then, press the FLOPPY DISK
touchscreen button in the Title Manager Window. If loading from Flash Memory, press the FLASH
MEMORY touchscreen button.
2 Select the Title to be loaded by touching its number (only one Title will be displayed if loading from
floppy disk; up to ten will be displayed if loading from Flash Memory). Information about the Title,
including its file size, date and time created, and sample rate, is displayed in the INFORMATION section
of the Title Manager Window.
3 Press the LOAD button. The following dialog will appear: (See Figure 9)
Loading A Title
Figure 9
