Sony DSC-T77 - ST-199 Flexible Board Attachment

DSC-T77_L2
HELP
ST-199 Flexible Board
ST-199 Flexible Board
ST-199 Flexible
Board
ST-199 Flexible
Board
Valley Hold
Valley Hold
Mountain Hold
Mountain Hold
Mountain Hold
Mountain Hold
ST Holder
1
Fold dotted line parts of ST-199 flexible board as shown in figure.
2
Install ST-199 Flexible board to ST holder as shown in figure.
THE METHOD OF ATTACHMENT OF ST-199 FLEXIBLE BOARD
Claw
Claws
Claws
HELP12
