Sony DSC-U20 - Mounted Parts Location

4-60
DSC-U20
COVER
COVER
4-60
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
CD-425 FLEXIBLE BOARD
4-5. MOUNTED PARTS LOCATION
no mark : side A
* mark : side B
C301 C-1
C302 B-1
C303 C-1
C305 C-1
C306 C-1
C307 C-1
C309 C-1
C310 C-1
C313 C-1
C314 C-1
C315 C-1
D301 C-1
FB301 C-1
IC101 A-1
* IC302 C-1
L301 B-1
Q302 C-2
R301 C-1
R302 C-1
R303 C-2
R304 C-2
R306 C-1
R307 C-2
R308 C-2
R309 C-2
R310 C-2
R311 B-1
CD-425
