Sony DSC-U20 - Sl-59 Flexible

Ref. No. Part No. Description Ref. No. Part No. Description
DSC-U20
5-11
SL-59 FLEXIBLE ST-79 SW-376 FLEXIBLE
0 A-7078-517-A SL-59 FLEXIBLE BOARD, COMPLETE
*****************************
(Including ST-79 board)
0 1-477-336-11 FLASH UNIT
< CAPACITOR >
0 C601 1-100-019-11 ELECT 42uF 99% 330V
< COIL >
0 L601 1-424-770-11 COIL, TRIGGER
ST-79 BOARD, COMPLETE (Not supplied)
**********************
(Included SL-59 flexible board)
< CAPACITOR >
C503 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C504 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C506 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C508 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C509 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C511 1-137-723-21 CERAMIC CHIP 0.047uF 10% 250V
< DIODE >
D501 8-719-073-01 DIODE MA111- (K8).S0
0 D502 6-500-237-01 DIODE HAU160C030TP
< COIL >
L501 1-419-627-21 INDUCTOR 10uH
< TRANSISTOR >
0 Q501 8-729-052-64 TRANSISTOR DTC144EHT2L
0 Q502 8-729-055-89 TRANSISTOR MCH3306-TL-E
0 Q503 6-550-308-01 TRANSISTOR CPH3205-SONY-TL-E
0 Q504 8-729-053-57 TRANSISTOR RN1902FE (TPLR3)
0 Q505 8-729-053-57 TRANSISTOR RN1902FE (TPLR3)
0 Q506 8-729-052-55 TRANSISTOR DTA114EHT2L
0 Q507 8-729-042-28 TRANSISTOR 2SD2216J-QR (K8).SO
0 Q508 8-729-053-74 TRANSISTOR CY25AAJ-8-T13
< RESISTOR >
R501 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R502 1-218-977-11 RES-CHIP 100K 5% 1/16W
R503 1-218-965-11 RES-CHIP 10K 5% 1/16W
R505 1-218-990-11 SHORT CHIP 0
R506 1-218-949-11 RES-CHIP 470 5% 1/16W
R507 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R508 1-218-953-11 RES-CHIP 1K 5% 1/16W
R509 1-218-943-11 RES-CHIP 150 5% 1/16W
R510 1-218-937-11 RES-CHIP 47 5% 1/16W
R511 1-218-989-11 RES-CHIP 1M 5% 1/16W
R512 1-216-286-00 RES-CHIP 4.7M 5% 1/8W
R513 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R514 1-218-990-11 SHORT CHIP 0
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
< TRANSFORMER >
0 T502 1-437-987-21 TRANSFORMER, CONVERTER
A-7078-493-A SW-376 BOARD, COMPLETE
***********************
< CONNECTOR >
CN001 1-816-654-11 FFC/FPC CONNECTOR (LIF) 6P
< DIODE >
D001 8-719-053-07 DIODE SML-310MTT86
D002 8-719-056-53 DIODE MAZS051008SO
D003 8-719-056-53 DIODE MAZS051008SO
D004 8-719-056-53 DIODE MAZS051008SO
D005 8-719-056-53 DIODE MAZS051008SO
D006 8-719-056-53 DIODE MAZS051008SO
D007 8-719-056-23 DIODE MA2S111- (K8) .SO
< RESISTOR >
R001 1-216-817-11 METAL CHIP 470 5% 1/16W
R002 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R003 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R004 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S001 1-762-648-21 SWITCH, SLIDE (PLAY/STILL/MOVIE)
0 S002 1-786-157-21 SWITCH, TACTILE (POWER)
S003 1-786-370-11 TACTILE SWITCH (SHUTTER)
Electrical parts list of the TY-15 board is not
shown.
Pages 5-12 to 5-14 are not shown.
