Sony DSC-V3 User Manual

DSC-V3
2. DISASSEMBLY
2. DISASSEMBLY
2-3 2-4
HELP
HELP
1 Flexible board x1 : CN752
2 Connector
x2 : CN701, 704
3 Connector
x1 : CN401
4 Claw
x2
5 Lens block
1 Claw
x1
2 Grip assy
3 Connector x
1 : CN001
4 P2 tapping screw (M1.7)
x2
5 Connector x2 : CN083, 085
6 DD-217 board
7 Claw
x2
8 LI-072 flexible board
9 Claw
x1
0 BT-026 flexible board
qa Claw
x1
qs RE-003 flexible board
qd Screw (M1.7)
x2
qf CF-099 board
1 P2 tapping screw (M1.7)
x3
2 P2 torasuta screw (M1.7) x1
3 Grip block
1 P2 tapping screw (M1.7)
x3
2 JK-269 flexible board
1 Flexible board
x3 : CN201, 451, 763
2 P2 tapping screw (M1.7)
x1
3 SY-106 board
1
2
3
1
1
2
3
5
4
4
3
2
1
1
1
2
1
1
7
8
9
0
qa
qd
qf
qs
2
3
4
6
5
5
from Page 2-2
When removing the grip assy,
detents are firmly engaged
and therefore take care not to
get injured with projection, etc.
