4-71
DSC-V3
CD-515 FLEXIBLE BOARD
no mark : side A
*
mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
CD-515, CF-099
CF-099 BOARD
4-5. MOUNTED PARTS LOCATION
C101 A-2
C102 A-2
* C103 A-4
* C105 B-1
* C106 B-1
* C107 B-1
* CN101 B-4
* CN104 B-2
CN105 A-3
* D102 B-1
* D103 B-1
* D104 C-4
* D105 D-3
* D106 A-1
* L101 A-4
* Q101 D-4
* Q102 B-1
R102 A-1
R103 A-1
R104 A-2
R105 A-1
R106 A-2
R107 A-2
R108 A-2
R109 A-2
R110 A-2
R111 A-2
R112 A-3
R113 A-3
R114 A-3
* R115 B-1
R116 A-3
R117 A-3
R118 A-3
R119 A-3
R120 A-3
R121 A-3
R122 A-3
R123 A-3
R124 A-3
R125 A-3
* R126 A-4
* R127 A-4
* R128 B-1
* R129 B-1
* R130 B-1
* R131 B-1
* R132 D-4
* S101 D-4
C107 C-1
C108 C-1
C109 C-3
C110 C-3
FB101 C-3
Q102 C-1
Q103 B-1
Q104 C-1
Q105 C-1
R103 B-1
R104 B-1
R106 C-1
R110 B-1
R111 C-1
R112 C-2
R113 C-1
R114 B-1
R115 C-1
R116 C-1
R117 C-1
R118 C-1
R119 B-1

Sony DSC-V3 Specifications

General

Camera Type	Compact
Sensor Type	CCD
Effective Pixels	7.2 MP
Image Processor	Real Imaging Processor
Lens Type	Carl Zeiss Vario-Sonnar
Optical Zoom	4x
ISO Range	100 - 800
Shutter Speed	1/2000 - 30 sec
Display	LCD
Video Recording	640 x 480 at 30 fps
Flash	Built-in
Image Stabilization	No
Focal Length	7.1 - 28.4 mm
Aperture	f/2.8 - f/4
Storage	CompactFlash
