5-2. ELECTRICAL PARTS LIST
5-8
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-V3
0 A-1077-533-A AF-008 FLEXIBLE BOARD, COMPLETE (Note)
******************************
3-083-456-01 RETAINER, ASSIST LIGHT COVER
< DIODE>
0 D109 1-805-470-01 LASER UNIT (Note)
A-1077-527-A BB-005 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR>
CN301 1-778-594-21 CONNECTOR, BOARD TO
BOARD 80P
CN302 1-778-599-21 CONNECTOR, BOARD TO
BOARD 80P
A-1077-531-A BT-026 FLEXIBLE BOARD, COMPLETE
******************************
< BATTERY TERMINAL >
0BT001 1-780-061-11 BATTERY TERMINAL BOARD
A-1077-528-A CD-515 FLEXIBLE BOARD, COMPLETE
*******************************
(IC101 is not included in this complete board.)
< CAPACITOR >
C107 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-135-957-91 TANTAL. CHIP 10uF 20% 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< FERRITE BEAD >
FB101 1-414-921-11 INDUCTOR, FERRITE BEAD
< IC >
IC101 A-1076-017-A CCD BLOCK ASSY (CCD IMAGER) (Note)
< TRANSISTOR >
Q102 8-729-050-22 TRANSISTOR 2SC4250 (T5LSONY1)
Q103 8-729-037-74 TRANSISTOR UN9213J-(TX).SO
Q104 8-729-037-74 TRANSISTOR UN9213J-(TX).SO
Q105 8-729-037-74 TRANSISTOR UN9213J-(TX).SO
< RESISTOR >
R103 1-216-857-11 METAL CHIP 1M 5% 1/10W
R104 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R106 1-216-864-11 SHORT CHIP 0
R110 1-216-847-11 METAL CHIP 150K 5% 1/10W
R111 1-216-864-11 SHORT CHIP 0
R112 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R113 1-216-815-11 METAL CHIP 330 5% 1/10W
R114 1-216-864-11 SHORT CHIP 0
R115 1-216-864-11 SHORT CHIP 0
R116 1-216-864-11 SHORT CHIP 0
R117 1-216-864-11 SHORT CHIP 0
R118 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R119 1-216-803-11 METAL CHIP 33 5% 1/10W
A-1077-522-A CF-099 BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-100-662-11 TANTAL. CHIP 47uF 20% 6.3V
C105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C107 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN101 1-778-593-21 CONNECTOR, BOARD TO BOARD 60P
CN104 1-815-572-61 CONNECTOR, MEMORY STICK
CN105 1-818-801-21 PIN, CONNECTOR 50P (CF CARD)
< DIODE >
D102 6-500-813-01 DIODE MA2SD32008S0
D103 8-719-056-23 DIODE MA2S111-(K8).SO
D104 8-719-056-61 DIODE MAZS082008SO
D105 8-719-066-44 DIODE CL-270HR-C-TS
D106 8-719-056-23 DIODE MA2S111-(K8).SO
< COIL >
L101 1-469-549-21 INDUCTOR 1uH
< TRANSISTOR >
Q101 6-550-239-01 TRANSISTOR DTA144EMT2L
Q102 6-550-576-01 TRANSISTOR SSM6E01TU
< RESISTOR >
R102 1-218-937-11 RES-CHIP 47 5% 1/16W
R103 1-218-937-11 RES-CHIP 47 5% 1/16W
R104 1-218-990-11 SHORT CHIP 0
R105 1-218-937-11 RES-CHIP 47 5% 1/16W
R106 1-218-937-11 RES-CHIP 47 5% 1/16W
R107 1-218-937-11 RES-CHIP 47 5% 1/16W
R108 1-218-937-11 RES-CHIP 47 5% 1/16W
R109 1-218-937-11 RES-CHIP 47 5% 1/16W
R110 1-218-937-11 RES-CHIP 47 5% 1/16W
R111 1-218-937-11 RES-CHIP 47 5% 1/16W
R112 1-218-937-11 RES-CHIP 47 5% 1/16W
R113 1-218-937-11 RES-CHIP 47 5% 1/16W
R114 1-218-937-11 RES-CHIP 47 5% 1/16W
R115 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R116 1-218-937-11 RES-CHIP 47 5% 1/16W
R117 1-218-937-11 RES-CHIP 47 5% 1/16W
R118 1-218-937-11 RES-CHIP 47 5% 1/16W
AF-008 BB-005 BT-026 CD-515 CF-099
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
(Note) Be sure to read “Precautions for Replacement
of CCD Imager” on page 4-8 when changing
the CCD imager.
(Note) Be sure to read “SERVICE NOTE” on page 1-
2 when replacing the laser unit (D109).
