Sony DSC-W830 Service Manual

DSC-W830
1-1
1. REPAIR PARTS LIST
(ENGLISH)
NOTE:
• Due to standardization, replacements in the parts list may be different from
the parts specified in the diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have some differences from
the original one.
• Items marked “*” are not stocked since they are seldom required for routine
service. Some delay should be anticipated when ordering these items.
• CAPACITORS:
uF: μF
The components identified by mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0 sont
critiques pour la sécurité.
Ne les remplacer que par une pièce portant le numéro
spécifié.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。
• Color Indication of Appearance Parts
Example:
(SILVER) : Cabinet’s Color
(Silver) : Parts Color
• Abbreviation
AUS : Australian model
BR : Brazilian model
CH : Chinese model
CND : Canadian model
KR : Korea model
RU : Russian model

Sony DSC-W830 Specifications

General

Sensor Resolution	20.1 MP
Optical Zoom	8x
Lens Type	Carl Zeiss Vario-Tessar
Image Stabilization	Optical SteadyShot
LCD Screen Size	2.7 inches
Maximum Video Resolution	1280 x 720 (720p)
Sensor Size	1/2.3 inch
Image Sensor	Super HAD CCD
ISO Range	ISO 80-3200
Focal Length	4.5-36 mm
Digital Zoom	32x
LCD Resolution	230, 400 dots
ISO Sensitivity	Auto, 80, 100, 200, 400, 800, 1600, 3200
Battery Type	NP-BN
Dimensions	93.1 x 52.5 x 22.5 mm
Aperture	f/3.3 - f/6.3
Shutter Speed	2 to 1/1600 sec
Storage Media	Memory Stick Duo; SD/SDHC/SDXC
