Sony DSLR-A100 Service Manual

2-6
DSLR-A100_L2
2-1-2. HALF SET BODY-1
Follow the disassembly in the numerical order given.
1 FP-528 Flexible Board (1-1 to 1-22)
2 Power Unit (2-1 to 2-8)
3 AM-001 Board (3-1 to 3-25)
EXPLODED VIEW
A
A
B
B
C
C
D
D
E
E
F
F
H
H
I
I
J
J
K
K
L
L
G
G
1-1
1-2 (Fig. 2-2)
1-10
1-12
1-11
1-17
(Fig. 2-2)
1-21
(Fig. 2-2)
1-22
(Fig. 2-2)
1-13
1-18
(Fig. 2-4)
1-19
(Fig. 2-4)
1-20
1-14
1-8 (Fig. 2-3)
1-9
(Fig. 2-3)
1-3
1-5
1-7
1-6
1-15
1-4
1 FP-528
(Fig. 2-1)
3 AM-001 Board
(Fig. 2-8)
3-1
(Fig. 2-2)
3-17
(Fig. 2-6)
3-24
(Fig. 2-9)
3-4
(Fig. 2-7)
3-25
(Fig. 2-9)
3-2
(Fig. 2-3)
3-21
(Fig. 2-9)
3-22
(Fig. 2-9)
3-9
(Fig. 2-8)
3-16
3-18
3-20
3-23
3-19
3-3
3-5
3-7
3-8
3-10
3-11
3-12
3-13
3-14
3-15
3-6
1-16
2-1
2-7 (Fig. 2-2)
2-3
(Fig. 2-5)
2-4
(Fig. 2-5)
2-2
(Fig. 2-2)
2-8
2-5
2-6
2 Power Unit
AM-001
HELP

Sony DSLR-A100 Specifications

General

Sensor Type	CCD
Sensor Size	23.6 x 15.8 mm
Effective Pixels	10.2 MP
ISO Sensitivity	100 - 1600
Viewfinder Type	Optical (pentamirror)
Screen Size	2.5 inches
Continuous Shooting Speed	3 fps
Max Resolution	3872 x 2592
Image Ratio w:h	3:2
Focal Length Multiplier	1.5x
Screen Dots	230, 000
Max Shutter Speed	1/4000 sec
Min Shutter Speed	30 sec
Metering Modes	Multi-segment, Center-weighted, Spot
Exposure Compensation	-2 to +2 EV in 1/3 EV steps
WB Presets	7
USB	USB 2.0
Dimensions	133 x 95 x 71 mm
Image Stabilization	Yes (sensor-shift)
Weight	638 g
Storage Types	CompactFlash (Type I or II)
Battery	NP-FM55H
Lens Mount	Sony/Minolta Alpha
