Additional Information
Specifications
System
Laser Semiconductor laser
Signal format system NTSC
Audio characteristics
Frequency response DVD (PCM 96 kHz): 2 Hz to 44 kHz (±1.0 dB)
DVD (PCM 48 kHz): 2 Hz to 22 kHz (±0.5 dB)
CD: 2 Hz to 20 kHz (±0.5 dB)
Signal-to-noise ratio (S/N ratio) 115 dB (AUDIO OUT L/R jacks only)
Harmonic distortion 0.003%
Dynamic range DVD: 103 dB
CD: 99 dB
Wow and flutter Less than detected value (±0.001% W PEAK)
The signals from AUDIO OUT L/R jacks are measured. When you play PCM sound tracks with a 96 kHz sampling
frequency, the output signal from the DIGITAL OUT (OPTICAL) jack is converted to 48 kHz sampling frequency.
Outputs
General
Power requirements DC 10.5 V
See page 3 for further information.
Power consumption 12 W
Dimensions (approx.) 252
× 60 × 183 mm (10 × 2 3/8 × 7 1/4 in.) (width/height/depth)
including projecting parts
Mass (approx.) 1.5 kg (3 lb 5 oz)
Operating temperature 5°C to 35°C (41°F to 95°F)
Operating humidity 25% to 80%
Jack name Jack type Maximum output
level
Load impedance
DIGITAL OUT
(OPTICAL)
Optical output jack -18 dBm Wave length 660 nm
AUDIO OUT L/R Phono jack 2 Vrms (50 kilohms) Over 10 kilohms
VIDEO OUT Phono jack 1.0 Vp-p 75 ohms, sync negative
S-VIDEO OUT 4-pin mini DIN Luminance signal:
1.0 Vp-p
Color signal:
0.286 Vp-p
75 ohms, sync negative
75 ohms terminated
continued
