Sony DVP-S9 - Page 44

DVP-S9
4444
1.6 Vp-p
37 ns
3.4 Vp-p
37 ns
1.8 Vp-p
60.6 ns
3.4 Vp-p
37 ns
1 Vp-p
H
H
1 Vp-p
710 mVp-p
H
1 Vp-p
H
1 Vp-p
H
3.4 Vp-p
29.5 ns
3.4 Vp-p
44.3 ns
40.7 ns
3.4 Vp-p
3.4 Vp-p
29.5 ns
Approx.
600 mVp-p
Approx.
180 mVp-p
Approx.
800 mVp-p
Approx.
120 mVp-p
Approx.
1.4 Vp-p
Approx.
1.4 Vp-p
Approx.
1.4 Vp-p
Approx.
600 mVp-p
Approx.
180 mVp-p
Approx.
800 mVp-p
Approx.
120 mVp-p
Approx.
550 mVp-p
Approx.
570 mVp-p
•Waveforms
– RF Board –
1 IC001 2 (RF IN) (DVD PLAY)
2 IC001 2 (RF IN) (CD PLAY)
3 IC001 ra (TE) (DVD PLAY)
5 IC001 rs (FE) (DVD PLAY)
4 IC001 ra (TE) (CD PLAY)
6 IC001 rs (FE) (CD PLAY)
7 IC001 tl (SIGO) (DVD/CD PLAY)
– MB Board –
8 IC302 <zx, (RFIN2) (CD PLAY)
9 IC302 <zcz (RFIN1) (DVD PLAY)
0 IC302 <zcb (ADC0) (DVD PLAY)
qs IC302 <zcn (ADC1) (DVD PLAY)
qa IC302 <zcb (ADC0) (CD PLAY)
qd IC302 <zcn (ADC1) (CD PLAY)
qf IC302 <z,x (CLKIN), <z,m (MCKI), <z,. (SCKI)
qg IC503 qs (ACLK) (DVD PLAY)
qh IC503 qs (ACLK) (CD PLAY)
qj IC503 wl (CRPCLKI)
qk IC503 uf (YOUT) (COLOR BAR (NTSC))
ql IC503 uf (YOUT) (COLOR BAR (PAL))
w; IC503 uj (COUT) (COLOR BAR (NTSC))
wa IC503 uj (COUT) (COLOR BAR (PAL))
ws IC503 i; (COMPOUT)
(COLOR BAR (NTSC))
wd IC503 i; (COMPOUT)
(COLOR BAR (PAL))
wf IC503 <z,/ (CLKI), <z,x (SCLKIN)
wh IC102 3 (27-1OUT)
wg IC103 tf (X0)
wj IC102 7 (XTI)
710 mVp-p
H
