DVP-S9
SECTION 8
ELECTRICAL PARTS LIST DISC SENSOR
DRIVER IN OUT SW MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-678-463-11 DISC SENSOR BOARD
******************
< PHOTO REFLECTOR >
IC751 8-749-924-30 PHOTO REFLECTOR GP2S28
(DISC IN DETECT)
< RESISTOR >
R751 1-249-407-11 CARBON 150 5% 1/4W
**************************************************************
1-678-460-11 DRIVER BOARD
*************
< CAPACITOR >
C701 1-124-261-00 ELECT 10uF 20% 50V
C705 1-124-261-00 ELECT 10uF 20% 50V
C706 1-164-159-11 CERAMIC 0.1uF 50V
C707 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-785-324-11 PIN, CONNECTOR (STRAIGHT) 12P
CN702 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
CN703 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN704 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN705 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC701 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W
R705 1-249-435-11 CARBON 33K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W
R707 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Refer to servicing notes (page 4) for discrimi-
nation of TYPE A/B.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
1-678-462-11 IN OUT SW BOARD
****************
< SWITCH >
S741 1-771-821-11 SWITCH, PUSH (1 KEY) (IN)
S742 1-771-821-11 SWITCH, PUSH (1 KEY) (OUT)
**************************************************************
A-4727-237-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-164-159-11 CERAMIC 0.1uF 50V
C102 1-164-159-11 CERAMIC 0.1uF 50V
C401 1-126-934-11 ELECT 220uF 20% 10V
C402 1-126-934-11 ELECT 220uF 20% 10V
C403 1-164-159-11 CERAMIC 0.1uF 50V
C404 1-164-159-11 CERAMIC 0.1uF 50V
C405 1-164-159-11 CERAMIC 0.1uF 50V
C406 1-126-934-11 ELECT 220uF 20% 10V
C407 1-126-934-11 ELECT 220uF 20% 10V
C408 1-164-159-11 CERAMIC 0.1uF 50V
C411 1-164-159-11 CERAMIC 0.1uF 50V
C425 1-162-282-31 CERAMIC 100PF 10% 50V
C427 1-162-282-31 CERAMIC 100PF 10% 50V
C500 1-164-159-11 CERAMIC 0.1uF 50V
C501 1-126-768-11 ELECT 2200uF 20% 16V
C502 1-126-935-11 ELECT 470uF 20% 10V
C504 1-164-159-11 CERAMIC 0.1uF 50V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-164-159-11 CERAMIC 0.1uF 50V
C507 1-164-159-11 CERAMIC 0.1uF 50V
C508 1-126-964-11 ELECT 10uF 20% 50V
C509 1-126-935-11 ELECT 470uF 20% 10V
C512 1-164-159-11 CERAMIC 0.1uF 50V
C513 1-126-935-11 ELECT 470uF 20% 10V
C514 1-126-947-11 ELECT 47uF 20% 10V
C557 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN101 1-568-419-11 PIN, CONNECTOR 9P
CN102 1-568-373-11 PIN, CONNECTOR 8P
CN103 1-566-859-11 SOCKET, CONNECTOR 15P
(SYSTEM CONTROL 5 FROM TC-S9)
•Abbreviation
AUS: Australian model
EA : Saudi Arabia model
KR : Korean model
MX : Mexican model
SP : Singapore model
TH : Thai model
