DVP-S9
7
3-3. CD MECHANISM DECK (CDM63D)
Note: Follow the disassembly procedure in the numerical order given.
3-2. COVER
1 two screws
(case 3 TP2)
3 cover
2 screw
(BVTT3 × 6)
1 two screws
(case 3 TP2
)
3 four screws
(BVTP3
× 8)
2 connector
(CN701)
4 CD mechanism deck
(CDM63D)
5 wire (flat type) (25 core)
(CN010)
1 wire (flat type) (9 core
)
(CN015)
