Sony DWT-B03R - Block Diagram

17
Block Diagram
1: GND
2: +5.2 V
(output)
3: Hot +5.2 V
Attenuator
Head amp.
A/D converter
Internal SG
Audio codec
modulator
High-
frequency
circuit
Low-cut
filter
Digital signal processor
