REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
60
D703 8-719-901-83 DIODE 1SS83
D705 8-719-302-43 DIODE ELIZ
D706 8-719-901-83 DIODE 1SS83
D707 8-719-901-83 DIODE 1SS83
D708 8-719-109-97 DIODE RD6.8ES-B2
D709 8-719-109-97 DIODE RD6.8ES-B2
D710 8-719-109-97 DIODE RD6.8ES-B2
D1801 8-719-110-17 DIODE RD10ESB2
D1802 8-719-110-17 DIODE RD10ESB2
D1803 8-719-110-17 DIODE RD10ESB2
< IC >
IC701 8-759-562-43 IC TDA6108JF/N1B
IC1801 8-759-603-37 IC M5216P
< SOCKET >
J701 £ 1-251-732-11 SOCKET, CRT
< COIL >
L704 1-414-183-41 INDUCTOR 10UH
< RESISTOR >
R701 1-247-903-00 CARBON 1M 5% 1/4W
R702 1-249-429-11 CARBON 10K 5% 1/4W
R703 1-247-903-00 CARBON 1M 5% 1/4W
R704 1-535-143-21 LEAD, JUMPER (12.5MM)
R705 1-215-869-11 METAL OXIDE 1K 5% 1W
R706 1-249-411-11 CARBON 330 5% 1/4W
R712 1-215-869-11 METAL OXIDE 1K 5% 1W
R716 1-249-411-11 CARBON 330 5% 1/4W
R718 1-202-814-11 SOLID 33K 10% 1/2W
R726 1-215-869-11 METAL OXIDE 1K 5% 1W
R727 1-249-411-11 CARBON 330 5% 1/4W
R728 1-249-398-11 CARBON 27 5% 1/4W
R741 1-202-549-00 SOLID 100 20% 1/2W
R1801 1-249-441-11 CARBON 100K 5% 1/4W
R1805 1-249-429-11 CARBON 10K 5% 1/4W
R1806 1-247-899-11 CARBON 680K 5% 1/4W
R1807 1-249-429-11 CARBON 10K 5% 1/4W
R1808 1-249-429-11 CARBON 10K 5% 1/4W
R1809 1-249-429-11 CARBON 10K 5% 1/4W
R1810 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV702 1-241-656-21 RES, ADJ, METAL FILM 110M
plete
D3
C
D2
*A-1640-431-A D3 Board, Complete
< CAPACITOR >
C2802 1-126-965-91 ELECT 22UF 20.00% 50V
< CONNECTOR >
CN2801 *1-564-506-11 PLUG, CONNECTOR 3P
CN2802 *1-785-270-12 PIN, DY CONNECTOR (PC BOARD)
CN2803 *1-580-798-11 CONNECTOR PIN (DY) 6P
< DIODE >
D2801 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q2801 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q2802 8-729-900-95 TRANSISTOR 2SC1740S-RT
< RESISTOR >
R2801 1-249-421-11 CARBON 2.2K 5% 1/4W
R2802 1-247-839-91 CARBON 2.2K 5% 1/4W
< RELAY >
RY2801 1-755-172-11 RELAY
< TRANSFORMER >
T2801 1-411-981-11 INDUCTOR 245UH
*A-1642-285-A D2 Board, Complete (KV-28LS35)
*A-1642-281-A D2 Board, Complete (KV-32LS35)
D2 Board, Common Parts
< CAPACITOR >
C8802 1-136-104-00 FILM 0.16UF 5.00% 200V
C8804 1-136-207-11 MYLAR 0.047UF 10.00% 250V
< CONNECTOR >
CN8801 *1-778-770-11 CONNECTOR,BOARD TO BOARD(PLUG)
CN8802 *1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D8801 8-719-923-60 DIODE MTZJ-T-77-9.1A
D8802 8-719-936-85 DIODE RGP10GPKG23
D8803 8-719-921-39 DIODE MTZJ4.7B
< IC >
IC8801 8-749-010-64 PHOTO COUPLER PC123F2
