Sony FD Trinitron KV-28LS35E - Page 48

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
61
D2
C1845 1-129-725-00 FILM 0.082UF 5.00% 400V
C1901 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C1902 1-137-374-11 MYLAR 0.047UF 5.00% 50V
C1903 1-126-964-11 ELECT 10UF 20.00% 50V
C1904 1-137-366-11 MYLAR 0.0022UF 5.00% 50V
C1905 1-137-374-11 MYLAR 0.047UF 5.00% 50V
C1906 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1913 1-129-898-91 FILM 0.0022UF 5.00% 630V
C1915 1-136-205-11 MYLAR 0.022UF 10.00% 250V
C1916 1-162-962-91 CERAMIC CHIP 470PF 10.00% 50V
C1917 1-102-228-00 CERAMIC 470PF 10.00% 500V
C1951 1-126-964-11 ELECT 10UF 20.00% 50V
C1952 1-126-964-11 ELECT 10UF 20.00% 50V
C1953 1-137-367-11 MYLAR 0.0033UF 5.00% 50V
C1954 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1957 1-126-964-11 ELECT 10UF 20.00% 50V
C1958 1-136-169-00 FILM 0.22UF 5.00% 50V
C1959 1-136-169-00 FILM 0.22UF 5.00% 50V
< CONNECTOR >
CN1701 *1-691-771-11 PLUG, CONNECTOR 9P
CN1702 *1-564-506-11 PLUG, CONNECTOR 3P
CN1718 *1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
CN1809 1-695-915-11 TAB (CONTACT)
< DIODE >
D1711 8-719-988-61 DIODE 1SS355TE-17
D1719 8-719-991-33 DIODE 1SS133T-77
D1722 8-719-991-33 DIODE 1SS133T-77
D1733 8-719-921-40 DIODE MTZJ-4.7C
D1734 8-719-921-40 DIODE MTZJ-4.7C
D1840 8-719-302-43 DIODE EL1Z
D1901 8-719-991-33 DIODE 1SS133T-77
D1902 8-719-991-33 DIODE 1SS133T-77
D1903 8-719-991-33 DIODE 1SS133T-77
D1904 8-719-991-33 DIODE 1SS133T-77
D1905 8-719-110-41 DIODE RD15ES-B2
D1906 8-719-970-87 DIODE ERA38-06
D1907 8-719-970-87 DIODE ERA38-06
D1908 8-719-300-33 DIODE RU-3AM
D1909 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB1701 1-535-143-61 LEAD, JUMPER (5.0MM)
< IC >
IC1701 8-759-394-36 IC BA09T
IC1901 8-759-450-95 IC LM393N
IC1902 8-759-008-70 IC LM358N
VM
< COIL >
L8802 1-406-978-21 COIL CHOKE 150UH
< TRANSISTOR >
Q8801 8-729-034-09 TRANSISTOR 2SK2518-01MR
Q8802 8-729-027-59 TRANSISTOR DTC144EKA-T146
Q8803 8-729-027-59 TRANSISTOR DTC144EKA-T146
< RESISTOR >
JR8801 1-216-864-91 SHORT 0
R8803 1-249-441-11 CARBON 100K 5% 1/4W
R8804 1-216-825-91 RES-CHIP 2.2K 5% 1/16W
R8805 1-216-825-91 RES-CHIP 10K 5% 1/16W
R8806 1-216-809-91 RES-CHIP 100 5% 1/16W
R8812 1-218-879-91 RES-CHIP 22K 0.5% 1/16W
D2 Board Variant Parts KV-28LS35
< CAPACITOR >
C8803 1-115-521-11 FILM 0.82UF 5.00% 250V
D2 Board Variant Parts KV-32LS35
< CAPACITOR >
C8803 1-115-356-11 FILM 1.2UF 5.00% 250V
*A-1645-050-A VM Board, Complete (KV-28LS35)
*A-1645-049-A VM Board, Complete (KV-32LS35)
VM Board, Common Parts
4-352-844-01 PIN, LEAD, COATING
< CAPACITOR >
C1701 1-104-665-11 ELECT 100UF 20.00% 25V
C1702 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1703 1-162-955-11 CERAMIC CHIP 150PF 5.00% 50V
C1704 1-104-665-11 ELECT 100UF 20.00% 25V
C1705 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C1710 1-106-375-12 MYLAR 0.022UF 10.00% 250V
C1711 1-106-375-12 MYLAR 0.022UF 10.00% 250V
C1713 1-106-375-12 MYLAR 0.022UF 10.00% 250V
C1721 1-107-655-91 ELECT 47UF 20.00% 250V
C1722 1-136-153-00 FILM 0.01UF 5.00% 50V
C1723 1-126-935-11 ELECT 470UF 20.00% 10V
C1728 1-126-935-11 ELECT 470UF 20.00% 10V
C1733 1-104-664-11 ELECT 47UF 20.00% 25V
C1734 1-104-664-11 ELECT 47UF 20.00% 25V
C1737 1-104-999-51 FILM 0.1UF 5.00% 200V
C1844 1-129-716-00 FILM 0.015UF 5.00% 630V
