Sony FD Trinitron KV-28LS35E - Page 49

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
62
< COIL >
L1701 1-414-183-41 INDUCTOR 10UH
L1702 1-412-525-41 INDUCTOR 10UH
L1703 1-414-184-31 INDUCTOR 15UH
L1843 1-406-989-21 INDUCTOR 10MH
L1901 1-406-677-21 INDUCTOR 10MMH
< TRANSISTOR >
Q1701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1704 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1705 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1706 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q1707 8-729-049-09 TRANSISTOR BC327-25
Q1708 8-729-045-05 TRANSISTOR 2SA2005
Q1709 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1710 8-729-049-10 TRANSISTOR BC337-25
Q1711 8-729-045-04 TRANSISTOR 2SC5511
Q1840 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1841 8-729-039-68 TRANSISTOR IRF620
Q1901 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1902 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1903 8-729-043-95 TRANSISTOR 2SC3840(3)
Q1906 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1907 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
JR1702 1-216-814-11 RES-CHIP 270 5% 1/16W
R1701 1-216-814-11 RES-CHIP 270 5% 1/16W
R1702 1-216-814-11 RES-CHIP 270 5% 1/16W
R1709 1-216-824-91 RES-CHIP 1.8K 5% 1/16W
R1710 1-216-839-11 RES-CHIP 33K 5% 1/16W
R1711 1-216-823-11 RES-CHIP 1.5K 5% 1/16W
R1712 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R1713 1-216-809-11 RES-CHIP 100 5% 1/16W
R1714 1-260-089-11 CARBON 150 5% 1/2W
R1719 1-216-822-11 RES-CHIP 1.2K 5% 1/16W
R1720 1-247-863-91 CARBON 22K 5% 1/4W
R1721 1-247-863-91 CARBON 22K 5% 1/4W
R1722 1-216-822-11 RES-CHIP 1.2K 5% 1/16W
R1723 1-249-399-11 CARBON 33 5% 1/4W
R1724 1-216-830-91 RES-CHIP 5.6K 5% 1/16W
R1725 1-247-889-91 CARBON 270K 5% 1/4W
R1726 1-247-889-91 CARBON 270K 5% 1/4W
R1727 1-216-830-91 RES-CHIP 5.6K 5% 1/16W
R1728 1-249-399-11 CARBON 33 5% 1/4W
R1729 1-249-407-11 CARBON 150 5% 1/4W
R1732 1-249-407-11 CARBON 150 5% 1/4W
R1733 1-214-809-81 METAL 5.1 1% 1/2W
VM
R1734 1-214-809-81 METAL 5.1 1% 1/2W
R1735 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R1736 1-215-892-21 METAL OXIDE 1K 5% 2W
R1737 1-215-867-00 METAL OXIDE 470 5% 1W
R1739 1-535-143-61 LEAD JUMPER (5.00MM)
R1842 1-216-809-11 RES-CHIP 100 5% 1/16W
R1846 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R1901 1-216-841-11 RES-CHIP 47K 5% 1/16W
R1903 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1904 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1905 1-216-845-11 RES-CHIP 100K 5% 1/16W
R1906 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1907 1-216-845-11 RES-CHIP 100K 5% 1/16W
R1908 1-216-813-11 RES-CHIP 220 5% 1/16W
R1909 1-215-489-00 METAL 680K 1% 1/4W
R1910 1-216-864-91 SHORT 0
R1911 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1912 1-216-857-11 RES-CHIP 1M 5% 1/16W
R1913 1-216-821-11 RES-CHIP 1K 5% 1/16W
R1914 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R1915 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R1917 1-216-842-11 RES-CHIP 56K 5% 1/16W
R1918 1-215-921-11 METAL OXIDE 4.7K 5% 3W
R1919 1-218-871-91 RES-CHIP 10K 5% 1/16W
R1920 1-216-864-91 SHORT 0
R1921 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R1923 1-216-845-11 RES-CHIP 100K 5% 1/16W
R1924 1-216-845-11 RES-CHIP 100K 5% 1/16W
R1925 1-216-845-11 RES-CHIP 100K 5% 1/16W
R1953 1-216-850-11 RES-CHIP 270K 5% 1/16W
R1954 1-216-851-11 RES-CHIP 330K 5% 1/16W
R1955 1-216-849-11 RES-CHIP 220K 5% 1/16W
R1956 1-218-463-11 RES-CHIP 8.2M 5% 1/10W
R1957 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1958 1-216-809-11 RES-CHIP 100 5% 1/16W
R1959 1-216-828-11 RES-CHIP 3.9K 5% 1/16W
R1962 1-216-839-11 RES-CHIP 33K 5% 1/16W
R1964 1-216-809-11 RES-CHIP 100 5% 1/16W
R1965 1-216-817-11 RES-CHIP 470 5% 1/16W
R1967 1-216-483-11 METAL OXIDE 2.7K 5% 3W
R1968 1-215-886-11 METAL OXIDE 100 5% 2W
R1969 1-216-483-11 METAL OXIDE 2.7K 5% 3W
< TRANSFORMER >
T1901 1-424-584-11 TRANSFORMER, DYNAMIC FOCUS
