REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: Les composants identies per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specie.
CONNECTOR
CN501 1-793-239-11 PIN, CONNECTOR (PC BOARD) 6P
* CN601 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
*
!
CN602 1-691-960-11 PIN, CONNECTOR (PC BOARD)
CN604 1-770-724-11 CONNECTOR, BOARD TO BOARD 9P
* CN701 1-764-333-11 PIN, CONNECTOR(PCB)(V TYPE)10P
CN904 1-695-915-11 TAB (CONTACT)
* CN1101 1-508-879-11 BASE POST 4P
CN1102 1-774-628-11 CONNECTOR, BOARD TO BOARD 17P
* CN1103 1-564-511-11 PLUG, CONNECTOR 8P
DIODE
D401 8-719-979-61 DIODE EGP10GPKG23
D405 8-719-109-85 DIODE RD5.1ESB2
D406 8-719-050-84 DIODE RB441Q-40T-77
D501 8-719-110-47 DIODE RD18ESB
D502 8-719-054-71 DIODE D5SC4M-F
D503 8-719-110-47 DIODE RD18ESB
D504 8-719-066-36 DIODE FMQ-G5GS
D505 8-719-052-86 DIODE D2L40-TA
D506 8-719-062-89 DIODE HZS5B2-TE
D509 8-719-404-50 DIODE MA111-TX
D510 8-719-082-50 DIODE 11DF2N-TA2B2
D512 8-719-911-19 DIODE 1SS119-25
D516 8-719-052-90 DIODE D1NL40-TA2
D517 8-719-082-50 DIODE 11DF2N-TA2B2
D518 8-719-050-84 DIODE RB441Q-40T-77
D519 8-719-069-54 DIODE UDZSTE-175.1B
D520 8-719-911-19 DIODE 1SS119-25
D521 8-719-911-19 DIODE 1SS119-25
D610 8-719-510-53 DIODE D4SB60L
D613 8-719-304-63 DIODE RM11C
D631 8-719-063-73 DIODE D1NL20U-TR
D632 8-719-059-23 DIODE P6KE200AG23
D633 8-719-069-63 DIODE ERB38-06V1
D634 8-719-063-73 DIODE D1NL20U-TR
D635 8-719-110-67 DIODE RD27ESB2
D641 8-719-069-63 DIODE ERB38-06V1
D643 8-719-404-50 DIODE MA111-TX
D644 8-719-404-50 DIODE MA111-TX
D650 8-719-064-49 DIODE D4SBL40
D651 8-719-063-74 DIODE D1NL20U-TR2
D652 8-719-052-91 DIODE D4SBS4-F
D680 8-719-510-41 DIODE D10SC9M
D690 8-719-911-19 DIODE 1SS119-25
D692 8-719-911-19 DIODE 1SS119-25
D694 8-719-911-19 DIODE 1SS119-25
D697 8-719-404-50 DIODE MA111-TX
D701 8-719-911-19 DIODE 1SS119-25
D702 8-719-911-19 DIODE 1SS119-25
D703 8-719-911-19 DIODE 1SS119-25
D705 8-719-404-50 DIODE MA111-TX
D706 8-719-069-54 DIODE UDZSTE-175.1B
D901 8-719-404-50 DIODE MA111-TX
D906 8-719-083-63 DIODE UDZSTE-1713B
D907 8-719-052-86 DIODE D2L40-TA
D909 8-719-110-47 DIODE RD18ESB
D910 8-719-028-72 DIODE RGP02-17EL-6433
D911 8-719-018-82 DIODE RGP02-20EL-6394
D912 8-719-110-42 DIODE RD15ESB3
D914 8-719-970-83 DIODE HSS82-TJ
D917 8-719-069-60 DIODE UDZSTE-179.1B
D918 8-719-404-50 DIODE MA111-TX
D919 8-719-069-54 DIODE UDZSTE-175.1B
D920 8-719-977-28 DIODE DTZ10B
D921 8-719-911-19 DIODE 1SS119-25
D922 8-719-404-50 DIODE MA111-TX
D923 8-719-404-50 DIODE MA111-TX
FUSE
!
F601 1-576-233-11 FUSE 6.3A 250V
FERRITE BEAD
FB501 1-410-397-21 FERRITE 1.1µH
FB555 1-216-295-00 SHORT CHIP 1/8W
FB901 1-412-911-11 FERRITE 0µH
FB902 1-414-231-22 FERRITE 0µH
FB1000 1-414-231-22 FERRITE 0µH
FB1002 1-216-295-00 SHORT CHIP 1/8W
FB1005 1-216-295-00 SHORT CHIP 1/8W
FB1007 1-216-295-00 SHORT CHIP 1/8W
FUSE HOLDER
!
FH601 1-533-725-11 FUSE HOLDER 0A 0V
D
— 40 —
GDM-C520/C520K
