REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: Les composants identies per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specie.
IC
IC401 8-759-696-71 IC STV9379A
IC501 8-759-585-82 IC BA9759F-E2
IC610 8-749-018-08 IC MZ1532
IC620 8-759-670-30 IC MCZ3001D
IC630 8-759-535-32 IC FA13842P
IC640 8-749-018-07 IC SEB3-LF4
IC652 8-759-669-10 IC BA3953T-V5
IC654 8-759-701-79 IC NJM7812FA
IC680 8-759-682-42 IC MM1431ATT
IC701 8-759-822-38 IC LA6510
IC702 8-749-017-48 IC STK391-220
IC703 8-759-803-42 IC LA6500-FA
IC901 8-759-585-81 IC BA9758FS-E2
IC902 8-759-701-01 IC NJM2904M
CHIP CONDUCTOR
JR001 1-216-295-00 SHORT CHIP 1/8W
JR002 1-216-296-00 SHORT CHIP 1/4W
JR003 1-216-296-00 SHORT CHIP 1/4W
JR004 1-216-296-00 SHORT CHIP 1/4W
JR006 1-216-296-00 SHORT CHIP 1/4W
JR007 1-216-295-00 SHORT CHIP 1/8W
JR008 1-216-296-00 SHORT CHIP 1/4W
JR009 1-216-295-00 SHORT CHIP 1/8W
JR012 1-216-296-00 SHORT CHIP 1/4W
JR013 1-216-295-00 SHORT CHIP 1/8W
JR014 1-216-296-00 SHORT CHIP 1/4W
JR015 1-216-295-00 SHORT CHIP 1/8W
JR016 1-216-296-00 SHORT CHIP 1/4W
JR017 1-216-295-00 SHORT CHIP 1/8W
JR018 1-216-295-00 SHORT CHIP 1/8W
JR019 1-216-296-00 SHORT CHIP 1/4W
JR022 1-216-296-00 SHORT CHIP 1/4W
JUMPER WIRE
JW019 1-249-389-11 CARBON 4.7 5% 1/4W
COIL
L501 1-412-537-31 INDUCTOR 100µH
L502 1-419-871-12 COIL, HORIZONTAL LINEARITY
L504 1-406-673-81 INDUCTOR 2.2MH
L505 1-406-675-81 INDUCTOR 4.7MH
L506 1-406-673-81 INDUCTOR 2.2MH
L508 1-412-525-31 INDUCTOR 10µH
L509 1-419-869-31 COIL, HORIZONTAL CENTER
L510 1-411-594-41 INDUCTOR 5MH
!
L610 1-419-837-11 INDUCTOR 340µH
L611 1-419-397-11 INDUCTOR 68µH
L612 1-412-521-31 INDUCTOR 4.7µH
L652 1-406-665-11 INDUCTOR 100µH
L653 1-406-665-11 INDUCTOR 100µH
L680 1-408-615-31 INDUCTOR 100µH
L902 1-406-661-11 INDUCTOR 22µH
L1001 1-412-911-11 FERRITE 0µH
PHOTO COUPLER
!
PH610 8-749-018-06 IC TLP421F(D4-SONY)
!
PH620 8-749-018-06 IC TLP421F(D4-SONY)
!
PH630 8-749-018-06 IC TLP421F(D4-SONY)
TRANSISTOR
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-055-24 TRANSISTOR KTC3876S-Y-RTK
Q503 8-729-055-27 TRANSISTOR KTA1505S-Y-RTK
Q504 8-729-043-53 TRANSISTOR IRFU110
Q505 8-729-053-30 TRANSISTOR 2SC5570(LBSONY1)
Q506 8-729-050-13 TRANSISTOR 2SJ585LS-CC11
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-055-24 TRANSISTOR KTC3876S-Y-RTK
Q509 8-729-055-27 TRANSISTOR KTA1505S-Y-RTK
Q510 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q511 6-550-365-01 TRANSISTOR IRLI3615-LF33
Q512 6-550-188-01 TRANSISTOR 2SK3579-01MR-F119
Q513 8-729-046-62 TRANSISTOR FS30KMJ-3-AZ
Q514 6-550-118-01 TRANSISTOR IRLI3215-LF33
Q515 6-550-118-01 TRANSISTOR IRLI3215-LF33
Q516 6-550-118-01 TRANSISTOR IRLI3215-LF33
Q517 6-550-118-01 TRANSISTOR IRLI3215-LF33
Q519 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q521 8-729-901-00 TRANSISTOR DTC124EK
Q523 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q524 8-729-901-00 TRANSISTOR DTC124EK
Q610 8-729-029-55 TRANSISTOR DTA143ZSA-TP
Q611 8-729-029-96 TRANSISTOR DTC143XSA
Q630 8-729-045-03 TRANSISTOR 2SK2647-01MR-F91
Q640 8-729-052-29 TRANSISTOR 2SK2876-01MR-F122
D
