Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E770W
102
D3071 6-500-335-01 DIODE MC2838-T112-1
D3072 6-501-817-01 DIODE MA2J1110GLS0
D3101 6-501-696-01 DIODE RSA39LTE25
D3102 6-501-696-01 DIODE RSA39LTE25
D3103 6-501-696-01 DIODE RSA39LTE25
D3104 6-501-696-01 DIODE RSA39LTE25
D3201 6-501-696-01 DIODE RSA39LTE25
D3202 6-501-696-01 DIODE RSA39LTE25
D3203 6-501-696-01 DIODE RSA39LTE25
D3204 6-501-696-01 DIODE RSA39LTE25
D3401 6-501-696-01 DIODE RSA39LTE25
D3402 6-501-696-01 DIODE RSA39LTE25
D3551 6-500-848-01 DIODE MC2840-T112-1
D3553 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
FB701 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB702 1-500-283-11 INDUCTOR, FERRITE BEAD
FB704 1-469-094-21 FERRITE, EMI (SMD) (1608)
FB705 1-400-580-21 FERRITE, EMI (SMD)
FB706 1-469-094-21 FERRITE, EMI (SMD) (1608)
< IC >
IC501 A-1748-298-A IC R5F364AMDFA (for SERVICE)
IC503 6-705-203-01 IC S-80935CNMC-G85T2G
IC505 6-705-337-01 IC TK11150CSCL-G
IC506 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC507 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC508 6-705-337-01 IC TK11150CSCL-G
IC700 6-600-466-01 IC TORX147L (SONY) (TV DIGITAL IN OPTICAL)
IC702 6-710-554-01 IC PCM1808PWR
IC703 6-713-642-01 IC LC89058W-E
IC704 6-707-853-01 IC TC74LCX541FT (EKJ)
IC3010 6-705-979-01 IC CXD9788AR
IC3011 6-712-613-01 IC SI-3010KM-TLS
IC3020 6-705-979-01 IC CXD9788AR
IC3050 6-714-743-01 IC MM3404A18URE
IC3051 6-706-492-01 IC TC7SHU04FU (T5RSOJF)
IC3100 6-714-477-01 IC CXD9981TN
IC3200 6-714-477-01 IC CXD9981TN
< JACK >
J700 1-784-431-21 JACK, PIN 1P (SAT/CABLE DIGITAL IN COAXIAL)
< COIL >
L700 1-481-524-11 INDUCTOR 10uH
L705 1-469-527-91 INDUCTOR 47uH
L3000 1-469-526-91 INDUCTOR 22uH
L3051 1-469-525-91 INDUCTOR 10uH
L3052 1-469-525-91 INDUCTOR 10uH
L3053 1-469-525-91 INDUCTOR 10uH
L3101 1-457-579-11 INDUCTOR 10uH
L3102 1-457-579-11 INDUCTOR 10uH
L3201 1-457-579-11 INDUCTOR 10uH
L3301 1-457-579-11 INDUCTOR 10uH
L3911 1-457-796-11 AIR-CORE COIL
L3912 1-457-797-11 AIR-CORE COIL
L3913 1-457-796-11 AIR-CORE COIL
L3914 1-457-797-11 AIR-CORE COIL
L3921 1-457-796-11 AIR-CORE COIL
L3922 1-457-797-11 AIR-CORE COIL
L3923 1-457-796-11 AIR-CORE COIL
L3924 1-457-797-11 AIR-CORE COIL
< TRANSISTOR >
Q504 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q507 6-551-272-01 TRANSISTOR RT3CLLM
Q3001 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q3101 6-551-271-01 TRANSISTOR RT3AMMM
Q3102 6-551-271-01 TRANSISTOR RT3AMMM
Q3201 6-551-271-01 TRANSISTOR RT3AMMM
Q3301 6-551-271-01 TRANSISTOR RT3AMMM
Q3551 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q3552 6-551-272-01 TRANSISTOR RT3CLLM
Q3556 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
< RESISTOR >
R504 1-216-809-11 METAL CHIP 100 5% 1/10W
R505 1-216-809-11 METAL CHIP 100 5% 1/10W
R506 1-216-821-11 METAL CHIP 1K 5% 1/10W
R507 1-216-815-11 METAL CHIP 330 5% 1/10W
R508 1-216-815-11 METAL CHIP 330 5% 1/10W
R509 1-216-815-11 METAL CHIP 330 5% 1/10W
R510 1-216-815-11 METAL CHIP 330 5% 1/10W
R511 1-216-815-11 METAL CHIP 330 5% 1/10W
R512 1-216-815-11 METAL CHIP 330 5% 1/10W
R513 1-216-815-11 METAL CHIP 330 5% 1/10W
R514 1-216-821-11 METAL CHIP 1K 5% 1/10W
R519 1-216-833-11 METAL CHIP 10K 5% 1/10W
R521 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W
R522 1-216-833-11 METAL CHIP 10K 5% 1/10W
R523 1-216-833-11 METAL CHIP 10K 5% 1/10W
R524 1-216-833-11 METAL CHIP 10K 5% 1/10W
R525 1-216-809-11 METAL CHIP 100 5% 1/10W
R527 1-216-821-11 METAL CHIP 1K 5% 1/10W
R528 1-216-821-11 METAL CHIP 1K 5% 1/10W
R529 1-216-821-11 METAL CHIP 1K 5% 1/10W
R530 1-216-809-11 METAL CHIP 100 5% 1/10W
R531 1-216-809-11 METAL CHIP 100 5% 1/10W
R532 1-216-809-11 METAL CHIP 100 5% 1/10W
R533 1-216-857-11 METAL CHIP 1M 5% 1/10W
R534 1-216-809-11 METAL CHIP 100 5% 1/10W
R536 1-216-809-11 METAL CHIP 100 5% 1/10W
R538 1-216-809-11 METAL CHIP 100 5% 1/10W
R542 1-216-833-11 METAL CHIP 10K 5% 1/10W
R544 1-216-864-11 SHORT CHIP 0
R545 1-216-833-11 METAL CHIP 10K 5% 1/10W
R546 1-216-809-11 METAL CHIP 100 5% 1/10W
R547 1-216-833-11 METAL CHIP 10K 5% 1/10W
R549 1-216-833-11 METAL CHIP 10K 5% 1/10W
R550 1-216-864-11 SHORT CHIP 0
R553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R555 1-216-833-11 METAL CHIP 10K 5% 1/10W
R556 1-216-809-11 METAL CHIP 100 5% 1/10W
R563 1-216-809-11 METAL CHIP 100 5% 1/10W
R565 1-216-801-11 METAL CHIP 22 5% 1/10W
R567 1-216-809-11 METAL CHIP 100 5% 1/10W
R568 1-216-864-11 SHORT CHIP 0
R569 1-216-809-11 METAL CHIP 100 5% 1/10W
R570 1-216-809-11 METAL CHIP 100 5% 1/10W
MAIN
Note: When IC3100 and IC3200 on the MAIN board are replaced, spread the compound
referring to “NOTE OF REPLACING THE IC3100 AND IC3200 ON THE MAIN
BOARD AND THE COMPLETE MAIN BOARD” on servicing notes (page 8).
