Pin No. Pin Name I/O Description
157 REGRST O REG reset signal output for Focus/Tracking/Sledding motor driver
158 MUTE O Mute signal output for Spindle motor
159 DDC_DA I/O HDMI DDC line data input/output
160 DVDD18 — Power supply (+1.8V)
161 DDC_CLK I/O HDMI DDC line clock input/output
162 HTPLG I HDMI HPD signal input
163 AGND3 — Ground
164 EXT_RES — Ext. resistor connected terminal
165, 166 AVDD3 — Power supply (+3.3V)
167 EXT_CAP — Ext. capacitor connected terminal
168, 169 AGND3, AGND18 — Ground
170 TXCN O HDMI TXD-clock output
171 TXCP O HDMI TXD-clock output
172 AVDD18 — Power supply (+1.8V)
173 TX0N O HDMI TXD-0 output
174 TX0P O HDMI TXD-0 output
175 AGND18 — Power supply (+1.8V)
176 TX1N O HDMI TXD-1 output
177 TX1P O HDMI TXD-1 output
178 AVDD18 — Power supply (+1.8V)
179 TX2N O HDMI TXD-2 output
180 TX2P O HDMI TXD-2 output
181 AGND18 — Power supply (+1.8V)
182 R/Cr/Pr O Video chroma R/Cr/Pr signal output
183 B/Cb/Pb O Video chroma B/Cb/Pb signal output
184 DACVSSA — Ground
185 Y/G O Video Y/chroma G signal output
186 DACVDDA — Power supply (+3.3V)
187 CVBS O Video Composite signal output
188 DACVSSB — Ground
189 C O Video chroma signal output (Not used in this set)
190 DACVDDB — Power supply (+3.3V)
191 Y O Video Y signal output (Not used in this set)
192 DACVSSC — Ground
193 FS I Full Scale Adjustment setting terminal
194 VREF I Reference Voltage input terminal
195 DACVDDC — Power supply (+3.3V)
196 VBUS_OE O VBUS power control signal output
197 VBUS_OC I VBUS over current detect signal input
198 SCORE/DIR_XSTATE — Not used. (Connected to ground)
199 SPMCK — Not used. (Connected to ground)
200 SPBCK — Not used. (Connected to ground)
201 SPLRCK — Not used. (Connected to ground)
202 ADIN (SPDATA) — Not used. (Connected to ground)
203 ACLK O A/D converter and DAMP clock output
204 ABCK O A/D converter and DAMP BCK clock output
205 ALRCK O A/D converter and DAMP LRCK clock output
206 MC_DATA (ADIN) I A/D converter digital data input
207 DVDD3 — Power supply (+3.3V)
208 MIC — Mic detect status signal input Not used. (Connected to ground)
209 WIDE O WIDE select signal output for EURO AV terminal
210 RGB_SEL/DSEL O Video output select signal output for EURO AV terminal
211 TRG_SW I Not used. (Pull up)
212 DVDD18 — Power supply (+3.3V)
213 KMOD O KARAOKE mode information signal output (Not used in this set)
214 XVOICE/DIR_CSFLAG — Not used. (Connected to ground)
215 SPDIF O Not used. (Open)
216 APLLVDD3 — Power supply (+3.3V)
217 APLLCAP — Ext capacitor connected terminal
