Sony HBD-TZ710 - Page 74

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-TZ210/TZ230/TZ510/TZ630/TZ710
74
R3056 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3057 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3058 1-216-817-11 METAL CHIP 470 5% 1/10W
R3059 1-216-864-11 SHORT CHIP 0
R3060 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3061 1-216-864-11 SHORT CHIP 0
R3062 1-216-805-11 METAL CHIP 47 5% 1/10W
R3063 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3064 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3065 1-216-817-11 METAL CHIP 470 5% 1/10W
R3066 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3067 1-216-805-11 METAL CHIP 47 5% 1/10W
R3069 1-216-805-11 METAL CHIP 47 5% 1/10W
R3070 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3071 1-216-801-11 METAL CHIP 22 5% 1/10W
R3072 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3073 1-216-809-11 METAL CHIP 100 5% 1/10W
R3074 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R3075 1-216-805-11 METAL CHIP 47 5% 1/10W
R3076 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3077 1-216-805-11 METAL CHIP 47 5% 1/10W
R3078 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3079 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3080 1-216-864-11 SHORT CHIP 0
R3081 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3082 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3083 1-216-864-11 SHORT CHIP 0
R3084 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3085 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3086 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3087 1-216-296-11 SHORT CHIP 0
(E3,E12,E32,AR,MX,PH,SP,TH)
R3093 1-216-864-11 SHORT CHIP 0
R3094 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3095 1-216-817-11 METAL CHIP 470 5% 1/10W
R3096 1-216-864-11 SHORT CHIP 0
R3097 1-216-805-11 METAL CHIP 47 5% 1/10W
R3098 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3099 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3100 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3102 1-216-817-11 METAL CHIP 470 5% 1/10W
R3103 1-216-805-11 METAL CHIP 47 5% 1/10W
R3104 1-216-805-11 METAL CHIP 47 5% 1/10W
R3105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3106 1-216-801-11 METAL CHIP 22 5% 1/10W
R3107 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R3108 1-216-809-11 METAL CHIP 100 5% 1/10W
R3109 1-216-805-11 METAL CHIP 47 5% 1/10W
R3110 1-216-805-11 METAL CHIP 47 5% 1/10W
R3111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3112 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3113 1-216-864-11 SHORT CHIP 0
R3114 1-216-864-11 SHORT CHIP 0
R3117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3119 1-216-805-11 METAL CHIP 47 5% 1/10W
R3121 1-216-857-11 METAL CHIP 1M 5% 1/10W
R3122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3123 1-216-864-11 SHORT CHIP 0
R3125 1-216-864-11 SHORT CHIP 0
R3127 1-216-864-11 SHORT CHIP 0
R3142 1-216-864-11 SHORT CHIP 0
R3143 1-216-864-11 SHORT CHIP 0
R3144 1-216-864-11 SHORT CHIP 0
R3145 1-216-864-11 SHORT CHIP 0
R9941 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9942 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9945 1-216-813-11 METAL CHIP 220 5% 1/10W
R9946 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB400 1-234-372-11 RES, NETWORK 100X4 (1005)
RB540 1-234-378-21 RES, NETWORK 10KX4 (1005)
RB541 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB550 1-234-372-11 RES, NETWORK 100X4 (1005)
RB603 1-234-372-11 RES, NETWORK 100X4 (1005)
RB1103 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1104 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1105 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1106 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1109 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1110 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1111 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1112 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1113 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1114 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1115 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1116 1-234-370-21 RES, NETWORK 22X4 (1005)
RB1117 1-234-370-21 RES, NETWORK 22X4 (1005)
RB1500 1-234-375-21 RES, NETWORK 1KX4 (1005)
< TERMINAL BOARD >
TB3001 1-780-838-11 TERMINAL BOARD (SPEAKER) 6P (SPEAKERS
(FRONT R/L,SUR R/L,CENTER,SUBWOOFER))
< VIBRATOR >
X501 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X1101 1-814-381-11 QUARTZ CRYSTAL UNITS (27MHz)
X3000 1-814-266-11 VIBRATOR, CRYSTAL (49.152MHz)
*************************************************************
MS-203 BOARD
************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION (CHUCK/TRAY DETECT)
*************************************************************
MAIN MS-203
Ver. 1.1
