Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-TZ210/TZ230/TZ510/TZ630/TZ710
76
D955 8-719-080-59 DIODE EK19-V0
0
DZ901 6-501-782-01 DIODE MAZ8180GMLS0
0
DZ902 6-502-231-01 DIODE MAZ8220GLLSO
0
DZ903 6-501-787-01 DIODE MAZ8220GMLS0
0
DZ905 6-501-792-01 DIODE MAZ8300GMLS0 (EXCEPT CND,MX,TW)
0
DZ905 8-719-083-71 DIODE UDZSUSTE-1730B (CND,MX,TW)
0
DZ915 6-501-760-01 DIODE MAZ8100GMLS0
0
DZ951 8-719-083-71 DIODE UDZSUSTE-1730B
0
DZ954 8-719-083-71 DIODE UDZSUSTE-1730B
(EXCEPT CND,MX,TW)
< FUSE >
0
F945 1-576-794-11 FUSE, MICRO (1608) 2A
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< RESISTOR >
0
FR929 1-246-373-11 FUSIBLE 1 10% 1/2W F
< IC >
0
IC901 6-707-741-01 IC STR-F6138-LF1352 (CND,MX,TW)
0
IC901 6-707-742-01 IC STR-F6168-LF1352 (EXCEPT CND,MX,TW)
0
IC921 6-714-671-01 IC STR-Y6763
IC923 6-711-947-01 IC MM1431CURE
IC932 6-711-947-01 IC MM1431CURE
IC941 6-712-613-01 IC SI-3010KM-TLS
< COIL >
L931 1-457-878-65 COIL, CHOKE 2.2uH
L954 1-457-578-11 COIL, CHOKE 10uH
L956 1-457-578-11 COIL, CHOKE 10uH
L964 1-457-725-11 COIL, CHOKE 4.7uH
L967 1-457-725-11 COIL, CHOKE 4.7uH
< LINE FILTER >
0
LF901 1-457-054-21 COIL, LINE FILTER
(EXCEPT CND,E32,EA,MX,TW)
0
LF901 1-457-449-11 COIL, LINE FILTER (CND,E32,EA,MX,TW)
0
LF902 1-457-054-21 COIL, LINE FILTER
(EXCEPT CND,E32,EA,MX,TW)
0
LF902 1-457-449-11 COIL, LINE FILTER (CND,E32,EA,MX,TW)
< PHOTO COUPLER >
0
PC901 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0
PC902 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0
PC903 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< TRANSISTOR >
0
Q901 8-729-201-53 TRANSISTOR 2SA1015-GR
0
Q922 6-550-702-01 TRANSISTOR 2SC3243-TP-E
Q943 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q945 6-552-458-01 FET 2SK3577-T1B-AT
Q949 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q950 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q969 6-551-699-01 TRANSISTOR ISA1602AM1TP-1EF
< RESISTOR >
0
R901 1-219-759-11 METAL 1M 5% 1/2W F
(CND,MX,TW)
0
R901 1-240-938-91 METAL 1.5M 5% 1/2W F
(EXCEPT CND,MX,TW)
0
R903 1-250-297-65 METAL OXIDE 100K 5% 3W F
(EXCEPT CND,MX,TW)
0
R903 1-250-299-65 METAL OXIDE 33K 5% 3W F
(CND,MX,TW)
0
R904 1-250-297-65 METAL OXIDE 100K 5% 3W F
(EXCEPT CND,MX,TW)
0
R904 1-250-299-65 METAL OXIDE 33K 5% 3W F
(CND,MX,TW)
0
R905 1-216-797-11 METAL CHIP 10 5% 1/10W
0
R906 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0
R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
0
R908 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0
R909 1-216-833-11 METAL CHIP 10K 5% 1/10W
0
R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0
R911 1-216-813-11 METAL CHIP 220 5% 1/10W
0
R912 1-216-363-00 METAL OXIDE 0.33 5% 2W F
(EXCEPT CND,MX,TW)
0
R914 1-220-891-11 METAL 0.1 10% 5W F
(EXCEPT CND,MX,TW)
0
R914 1-248-180-11 METAL 0.034 5% 5W F
(CND,MX,TW)
0
R916 1-250-297-65 METAL OXIDE 100K 5% 3W F
0
R917 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0
R919 1-216-837-11 METAL CHIP 22K 5% 1/10W
0
R922 1-250-262-41 METAL 0.39 5% 2W F
0
R923 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
0
R925 1-216-797-11 METAL CHIP 10 5% 1/10W
0
R926 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R931 1-216-864-11 SHORT CHIP 0
R932 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R933 1-216-821-11 METAL CHIP 1K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R938 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R939 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R940 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R941 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R942 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R945 1-216-837-11 METAL CHIP 22K 5% 1/10W
R946 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R949 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0
R951 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R952 1-216-864-11 SHORT CHIP 0
R954 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R955 1-216-821-11 METAL CHIP 1K 5% 1/10W
R956 1-216-817-11 METAL CHIP 470 5% 1/10W
R957 1-216-841-11 METAL CHIP 47K 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R959 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R962 1-216-864-11 SHORT CHIP 0
R963 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R965 1-216-864-11 SHORT CHIP 0
R966 1-216-821-11 METAL CHIP 1K 5% 1/10W
R967 1-216-821-11 METAL CHIP 1K 5% 1/10W
POWER
Note:
When IC921 on the Power board is damaged, exchange the
new Power board for the Power board which IC damaged.
Ver. 1.1
To Next Page
