Ref. No. Part No. Description Remark
HBD-TZ210/TZ230/TZ510/TZ630/TZ710
78
USB BOARD
**********
< CAPACITOR >
C5200 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5200 1-822-423-11 CONNECTOR, USB (A) 4P (USB)
CN5201 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
*************************************************************
USB KEY BOARD
**************
< CAPACITOR >
C5111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5112 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< RESISTOR >
R5125 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5126 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5127 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5128 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5129 1-216-864-11 SHORT CHIP 0
< ROTARY ENCODER >
S5113 1-480-136-11 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S5114 1-762-875-21 SWITCH, KEYBOARD (REC TO USB)
*************************************************************
MISCELLANEOUS
**************
102 1-828-322-11 WIRE (FLAT TYPE) (11 CORE)
104 1-828-955-11 WIRE (FLAT TYPE) (9 CORE)
0
106 1-834-288-12 CORD, POWER (TH)
0
106 1-834-966-41 CORD, POWER-SUPPLY
(E3,E12,E32,PH,RU,SAF,SP,AEP)
0
106 1-835-068-21 CORD, POWER (AUS)
0
106 1-835-078-31 CORD, POWER (EA,HK,UK)
0
106 1-837-308-11 CORD, POWER-SUPPLY (CND)
0
106 1-837-312-11 CORD, POWER-SUPPLY (AR)
0
106 1-837-344-11 CORD, POWER-SUPPLY (MX)
0
106 1-837-345-11 CORD, POWER-SUPPLY (TW)
0
106 1-837-822-21 CORD, POWER-SUPPLY (CH)
0
107 1-569-008-33 ADAPTOR, CONVERSION (E32)
109 1-823-718-11 WIRE (FLAT TYPE) (17 CORE) (TZ230/TZ630)
152 1-828-291-11 WIRE (FLAT TYPE) (5 CORE)
0
207 8-820-321-12 OPTICAL PICK-UP (KHM-313CAA/C2RP1)
208 1-828-773-51 WIRE (FLAT TYPE) (24 CORE)
0
F901 1-533-311-12 FUSE, GLASS (DIA. 5) (8A/125V) (CND,MX,TW)
0
F901 1-576-232-51 FUSE (H.B.C.) (5A/250V)
(EXCEPT CND,E32,EA,MX,TW)
0
F901 1-576-233-51 FUSE (H.B.C.) (6.3A/250V) (E32,EA)
TU401 1-693-780-21 TUNER (FM) (ANTENNA)
(EXCEPT CND,RU,SAF,AEP,UK,CH)
TU401 1-693-781-21 TUNER (FM) (ANTENNA) (CND)
TU401 1-693-788-21 TUNER (FM) (ANTENNA) (RU,SAF,AEP,UK,CH)
USB USB KEY
Ver. 1.1
To Next Page
