Sony HCD-BC250 - Page 78

78
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C269 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C271 1-115-156-11 CERAMIC CHIP 1uF 10V
C277 1-126-934-11 ELECT 220uF 20% 16V
C278 1-104-662-91 ELECT 22uF 20% 25V
C279 1-104-662-91 ELECT 22uF 20% 25V
C280 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C281 1-115-156-11 CERAMIC CHIP 1uF 10V
C282 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C284 1-104-662-91 ELECT 22uF 20% 25V
C288 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN200 1-568-830-11 CONNECTOR, FFC 11P
CN201 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN202 1-784-213-11 FFC/CONNECTOR, FPC (LIF (BIB-ZIF)) 14P
CN203 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< IC >
IC200 8-759-385-76 IC MC14052 BDR2
IC201 6-705-602-01 IC MM1623BFBE
IC203 8-759-710-97 IC NJM4565M-D
< JACK >
J200 1-764-593-21 JACK 2P (VIDEO/SAT)
J201 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J203 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
< COIL >
L200 1-414-754-11 INDUCTOR 10uH
L206 1-412-959-11 INDUCTOR 47uH
L207 1-414-754-11 INDUCTOR 10uH
L208 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q202 8-729-038-68 TRANSISTOR KRC103S
Q203 8-729-038-68 TRANSISTOR KRC103S
Q211 8-729-034-51 TRANSISTOR KTC3875
Q212 8-729-034-51 TRANSISTOR KTC3875
< RESISTOR >
R203 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R204 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R207 1-216-841-11 METAL CHIP 47K 5% 1/10W
R209 1-216-841-11 METAL CHIP 47K 5% 1/10W
R212 1-216-841-11 METAL CHIP 47K 5% 1/10W
R215 1-216-841-11 METAL CHIP 47K 5% 1/10W
R216 1-216-833-11 METAL CHIP 10K 5% 1/10W
R217 1-216-833-11 METAL CHIP 10K 5% 1/10W
R218 1-216-833-11 METAL CHIP 10K 5% 1/10W
R221 1-216-833-11 METAL CHIP 10K 5% 1/10W
R222 1-216-833-11 METAL CHIP 10K 5% 1/10W
R226 1-216-833-11 METAL CHIP 10K 5% 1/10W
R227 1-216-833-11 METAL CHIP 10K 5% 1/10W
R228 1-216-833-11 METAL CHIP 10K 5% 1/10W
R229 1-216-833-11 METAL CHIP 10K 5% 1/10W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R234 1-218-285-11 METAL CHIP 75 5% 1/10W
R235 1-216-821-11 METAL CHIP 1K 5% 1/10W
R236 1-216-809-11 METAL CHIP 100 5% 1/10W
R237 1-218-285-11 METAL CHIP 75 5% 1/10W
R238 1-218-285-11 METAL CHIP 75 5% 1/10W
R239 1-216-809-11 METAL CHIP 100 5% 1/10W
R244 1-216-833-11 METAL CHIP 10K 5% 1/10W
R248 1-216-833-11 METAL CHIP 10K 5% 1/10W
R251 1-216-821-11 METAL CHIP 1K 5% 1/10W
R253 1-216-839-11 METAL CHIP 33K 5% 1/10W
R254 1-216-839-11 METAL CHIP 33K 5% 1/10W
R256 1-216-839-11 METAL CHIP 33K 5% 1/10W
R257 1-216-839-11 METAL CHIP 33K 5% 1/10W
R259 1-216-841-11 METAL CHIP 47K 5% 1/10W
R260 1-216-841-11 METAL CHIP 47K 5% 1/10W
R263 1-216-833-11 METAL CHIP 10K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R268 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R271 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R272 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R275 1-216-817-11 METAL CHIP 470 5% 1/10W
R277 1-216-817-11 METAL CHIP 470 5% 1/10W
R284 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R285 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R286 1-216-813-11 METAL CHIP 220 5% 1/10W
R287 1-216-835-11 METAL CHIP 15K 5% 1/10W
R290 1-216-853-11 METAL CHIP 470K 5% 1/10W
R292 1-216-809-11 METAL CHIP 100 5% 1/10W
R293 1-216-835-11 METAL CHIP 15K 5% 1/10W
R294 1-216-853-11 METAL CHIP 470K 5% 1/10W
R295 1-216-813-11 METAL CHIP 220 5% 1/10W
R296 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R298 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R300 1-216-833-11 METAL CHIP 10K 5% 1/10W
R301 1-216-833-11 METAL CHIP 10K 5% 1/10W
R302 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R303 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R305 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
1-861-264-11 LF BOARD
********
< CAPACITOR >
0 C903 1-117-916-51 FILM 0.22uF 10% 275V
< CONNECTOR >
CN900 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN901 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
< LINE FILTER >
0 LF901 1-456-081-21 COIL, LINE FILTER (E41, EA, KR, AUS)
0 LF901 1-456-082-11 COIL, LINE FILTER (US, CND, MX, TW)
************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
IO LF
