79
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1052-864-A MAIN BOARD, COMPLETE (150: MX)
A-1053-127-A MAIN BOARD, COMPLETE (AUS)
A-1054-637-A MAIN BOARD, COMPLETE (E41)
A-1062-037-A MAIN BOARD, COMPLETE (250: US, CND)
A-1065-470-A MAIN BOARD, COMPLETE (EA)
A-1065-499-A MAIN BOARD, COMPLETE (TW, KR)
A-1067-908-A MAIN BOARD, COMPLETE (250: MX)
A-4752-751-A MAIN BOARD, COMPLETE (150: US, CND)
********************
< CAPACITOR >
C501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C506 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C509 1-126-964-11 ELECT 10uF 20% 50V
C510 1-104-658-91 ELECT 100uF 20% 10V
C511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C512 1-104-658-91 ELECT 100uF 20% 10V
C513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C514 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C515 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C516 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C517 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C519 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C520 1-126-947-11 ELECT 47uF 20% 35V
C521 1-126-923-91 ELECT 220uF 20% 10V
C522 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C524 1-104-905-11 CAPACITOR 0.22F 5.5V
C525 1-104-658-91 ELECT 100uF 20% 10V
C526 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C527 1-104-658-91 ELECT 100uF 20% 10V
C528 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C529 1-126-947-11 ELECT 47uF 20% 35V
C530 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C532 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C535 1-126-947-11 ELECT 47uF 20% 35V
C537 1-126-926-11 ELECT 1000uF 20% 10V
C539 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C540 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C546 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C547 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C548 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C549 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C550 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C552 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C553 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C554 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C555 1-126-916-11 ELECT 1000uF 20% 6.3V
C556 1-126-926-11 ELECT 1000uF 20% 10V
< CONNECTOR >
CN501 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN503 1-778-691-11 CONNECTOR, FFC/FPC 19P
CN504 1-785-466-11 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 7P
* CN505 1-784-365-31 CONNECTOR, FFC/FPC 5P
CN509 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN513 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB500 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB503 1-216-295-91 SHORT CHIP 0
FB505 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB508 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB509 1-469-324-21 FERRITE, EMI (SMD) (2012)
< IC >
IC509 6-804-494-01 IC uPD703260YGF-S21-JBT-A
IC511 6-701-680-01 IC PST3629NR
IC512 6-705-469-01 IC BA50BC0FP-E2
IC513 6-705-469-01 IC BA50BC0FP-E2
IC514 6-701-189-01 IC MC74VHC1GU04DFT1
IC515 6-701-011-01 IC uPC2910T-E1
IC516 6-705-470-01 IC BA70BC0FP-E2
< COIL >
L501 1-414-398-11 INDUCTOR 10uH
L502 1-414-398-11 INDUCTOR 10uH
L503 1-414-398-11 INDUCTOR 10uH
< TRANSISTOR >
Q505 8-729-038-54 TRANSISTOR KRA102S
Q506 8-729-034-51 TRANSISTOR KTC3875
Q507 8-729-034-51 TRANSISTOR KTC3875
Q508 8-729-034-51 TRANSISTOR KTC3875
Q509 8-729-034-49 TRANSISTOR KRC104S
< RESISTOR >
R501 1-216-809-11 METAL CHIP 100 5% 1/10W
R502 1-216-809-11 METAL CHIP 100 5% 1/10W
R503 1-216-809-11 METAL CHIP 100 5% 1/10W
R504 1-216-809-11 METAL CHIP 100 5% 1/10W
R505 1-216-809-11 METAL CHIP 100 5% 1/10W
R506 1-216-809-11 METAL CHIP 100 5% 1/10W
R507 1-216-821-11 METAL CHIP 1K 5% 1/10W
R508 1-216-809-11 METAL CHIP 100 5% 1/10W
R509 1-216-809-11 METAL CHIP 100 5% 1/10W
R510 1-216-809-11 METAL CHIP 100 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R514 1-216-809-11 METAL CHIP 100 5% 1/10W
R515 1-216-821-11 METAL CHIP 1K 5% 1/10W
R516 1-216-821-11 METAL CHIP 1K 5% 1/10W
R517 1-216-833-11 METAL CHIP 10K 5% 1/10W
MAIN
