Sony HCD-BC250 - Page 80

80
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R518 1-216-835-11 METAL CHIP 15K 5% 1/10W
R521 1-216-833-11 METAL CHIP 10K 5% 1/10W
(250: MX, CND)
R522 1-216-833-11 METAL CHIP 10K 5% 1/10W
(TW, EA, KR)
R522 1-216-835-11 METAL CHIP 15K 5% 1/10W
(AUS)
R522 1-216-841-11 METAL CHIP 47K 5% 1/10W
(US, CND, MX, E41)
R523 1-216-809-11 METAL CHIP 100 5% 1/10W
R530 1-216-809-11 METAL CHIP 100 5% 1/10W
R531 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R532 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R533 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(250)
R534 1-216-833-11 METAL CHIP 10K 5% 1/10W
R535 1-216-809-11 METAL CHIP 100 5% 1/10W
R536 1-216-833-11 METAL CHIP 10K 5% 1/10W
R537 1-216-809-11 METAL CHIP 100 5% 1/10W
R538 1-216-833-11 METAL CHIP 10K 5% 1/10W
R539 1-216-809-11 METAL CHIP 100 5% 1/10W
R540 1-216-833-11 METAL CHIP 10K 5% 1/10W
(MX, E41)
R540 1-216-837-11 METAL CHIP 22K 5% 1/10W
(US, CND)
R540 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EA, AUS)
R542 1-216-809-11 METAL CHIP 100 5% 1/10W
R543 1-216-864-11 SHORT CHIP 0
R546 1-216-809-11 METAL CHIP 100 5% 1/10W
R547 1-216-809-11 METAL CHIP 100 5% 1/10W
R548 1-216-821-11 METAL CHIP 1K 5% 1/10W
R549 1-216-833-11 METAL CHIP 10K 5% 1/10W
R550 1-216-809-11 METAL CHIP 100 5% 1/10W
R551 1-216-821-11 METAL CHIP 1K 5% 1/10W
R552 1-216-864-11 SHORT CHIP 0
R553 1-216-809-11 METAL CHIP 100 5% 1/10W
R555 1-216-821-11 METAL CHIP 1K 5% 1/10W
R556 1-216-833-11 METAL CHIP 10K 5% 1/10W
R558 1-216-833-11 METAL CHIP 10K 5% 1/10W
R560 1-216-833-11 METAL CHIP 10K 5% 1/10W
R562 1-216-821-11 METAL CHIP 1K 5% 1/10W
R563 1-216-833-11 METAL CHIP 10K 5% 1/10W
R564 1-216-833-11 METAL CHIP 10K 5% 1/10W
R565 1-216-833-11 METAL CHIP 10K 5% 1/10W
R566 1-216-833-11 METAL CHIP 10K 5% 1/10W
R567 1-216-841-11 METAL CHIP 47K 5% 1/10W
R568 1-216-833-11 METAL CHIP 10K 5% 1/10W
R571 1-216-833-11 METAL CHIP 10K 5% 1/10W
R572 1-216-833-11 METAL CHIP 10K 5% 1/10W
R573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R574 1-216-841-11 METAL CHIP 47K 5% 1/10W
R576 1-216-841-11 METAL CHIP 47K 5% 1/10W
R577 1-216-853-11 METAL CHIP 470K 5% 1/10W
R578 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R579 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R580 1-216-833-11 METAL CHIP 10K 5% 1/10W
R582 1-216-813-11 METAL CHIP 220 5% 1/10W
R586 1-216-809-11 METAL CHIP 100 5% 1/10W
R588 1-216-833-11 METAL CHIP 10K 5% 1/10W
R589 1-216-864-11 SHORT CHIP 0
R590 1-216-809-11 METAL CHIP 100 5% 1/10W
R591 1-216-809-11 METAL CHIP 100 5% 1/10W
R592 1-216-845-11 METAL CHIP 100K 5% 1/10W
R593 1-216-809-11 METAL CHIP 100 5% 1/10W
R594 1-216-809-11 METAL CHIP 100 5% 1/10W
R595 1-216-841-11 METAL CHIP 47K 5% 1/10W
R596 1-216-809-11 METAL CHIP 100 5% 1/10W
R598 1-216-809-11 METAL CHIP 100 5% 1/10W
R599 1-216-809-11 METAL CHIP 100 5% 1/10W
R600 1-216-833-11 METAL CHIP 10K 5% 1/10W
R601 1-216-809-11 METAL CHIP 100 5% 1/10W
R603 1-216-833-11 METAL CHIP 10K 5% 1/10W
R604 1-216-809-11 METAL CHIP 100 5% 1/10W
R605 1-216-833-11 METAL CHIP 10K 5% 1/10W
R607 1-216-833-11 METAL CHIP 10K 5% 1/10W
R609 1-216-864-11 SHORT CHIP 0
R610 1-216-864-11 SHORT CHIP 0
R611 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R612 1-216-864-11 SHORT CHIP 0
R613 1-216-809-11 METAL CHIP 100 5% 1/10W
R614 1-216-833-11 METAL CHIP 10K 5% 1/10W
R615 1-216-833-11 METAL CHIP 10K 5% 1/10W
R616 1-216-833-11 METAL CHIP 10K 5% 1/10W
R617 1-216-833-11 METAL CHIP 10K 5% 1/10W
R620 1-216-809-11 METAL CHIP 100 5% 1/10W
R621 1-216-845-11 METAL CHIP 100K 5% 1/10W
R624 1-216-841-11 METAL CHIP 47K 5% 1/10W
R690 1-216-864-11 SHORT CHIP 0
R691 1-216-864-11 SHORT CHIP 0
R692 1-216-864-11 SHORT CHIP 0
R693 1-216-864-11 SHORT CHIP 0
R698 1-216-864-11 SHORT CHIP 0
R699 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X501 1-795-058-21 VIBRATOR, CERAMIC
************************************************************
MOTOR BOARD
*************
< SWITCH >
S761 1-786-704-11 SWITCH, LEVER
************************************************************
A-4752-728-A PANEL BOARD, COMPLETE
**********************
4-255-281-01 LED HOLDER
< CAPACITOR >
C817 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C818 1-126-964-11 ELECT 10uF 20% 50V
C819 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C821 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C823 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
MAIN
MOTOR
PANEL
